Denon AVR-S900W Service Manual

HDMI
REF No. Part No. Part Name Remarks Q't
y
New
V
er
R1209,1210 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R1216,1217 nsp 10K-J,1/16W-1005REEL C20001036M111S 2
R1220 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R1221 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1222 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1233 nsp 47-J,1/16W-1005REEL C20004706M101S 1
R1234 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1235 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1236-1238 nsp 100-J,1/16W-1005REEL C20001016M101S 3
R1239 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R1240 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1241,1242 nsp 100-J,1/16W-1005REEL C20001016M101S 2
R1249,1250 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R1252 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1253 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1254 nsp 47-J 1/16W SMD(1005)*4 WA04X C180470042100S 1
R1255 nsp 10-F,1/16W-1005REEL C20001004M100S 1
R1258 nsp 47-J 1/16W SMD(1005)*4 WA04X C180470042100S 1
R1259-1261 nsp 0-J,1/16W-1005REEL C20000006M101S 3
R1263 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1264 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1332 nsp 22K-J,1/16W-1005REEL C20002236M101S 1
R1335 nsp 22K-J,1/16W-1005REEL C20002236M101S 1
R1337 nsp 22K-J,1/16W-1005REEL C20002236M101S 1
R1339 nsp 22K-J,1/16W-1005REEL C20002236M101S 1
R1341 nsp 22K-J,1/16W-1005REEL C20002236M101S 1
R1343 nsp 22K-J,1/16W-1005REEL C20002236M101S 1
R1344,1345 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 2
R1346 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R1347 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R1348 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R1349 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R1354 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R1355 nsp 18K-J,1/16W-1005REEL C20001836M101S 1
R1356 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R1357 nsp 120K-J,1/16W-1005REEL C20001246M101S 1
R1358 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R1359 nsp 120K-J,1/16W-1005REEL C20001246M101S 1
R1360 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R1362 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R1363 nsp 120K-J,1/16W-1005REEL C20001246M101S 1
R1364 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R1366 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1367,1368 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R1369 nsp 33K-J,1/16W-1005REEL C20003336M101S 1
R1370 nsp 18K-J,1/16W-1005REEL C20001836M101S 1
R1379 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1384 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1387-1390 nsp 33-J,1/16W-1005REEL C20003306M101S 4
R1393,1394 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 2
R1395 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1398,1399 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R1400 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1401-1407 nsp 33-J,1/16W-1005REEL C20003306M101S 7
R1410 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1412 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1414 nsp 10-J,1/16W-1005REEL C20001006M101S 1
R1418 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1421 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1422,1423 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R1425-1427 nsp 33-J,1/16W-1005REEL C20003306M101S 3
R1428 nsp 0-J,1/16W-1608REEL X2100E3 C20000006M160S 1
R1428 nsp 10K-J,1/16W-1608REEL E1/E1C C20001036M160S 1
R1428 nsp 22K-J,1/16W-1608REEL K C20002236M160S 1
R1428 nsp 3.3K-J,1/16W-1608REEL S900 C20003326M160S 1
R1431 nsp 0-J,1/16W-1608REEL E2 C20000006M160S 1
R1431 nsp 22K-J,1/16W-1608REEL E1 C20001036M160S 1
R1431 nsp 10K-J,1/16W-1608REEL E1C/K C20001036M160S 1
R1431 nsp 18K-J,1/16W-1608REEL S900 C20001836M160S 1
R1432-1434 nsp 1K-J,1/16W-1005REEL C20001026M101S 3
R1435 nsp 0-J,1/16W-1005REEL X2100E3 C20000006M101S 1
R1436 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1438-1441 nsp 33-J,1/16W-1005REEL C20003306M101S 4
R1442 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1443 nsp 1K-J,1/16W-1005REEL X2100E3 C20001026M101S 1
R1448 nsp 3.3K-J,1/16W-1005REEL X2100E3 C20003326M101S 1
R1450 nsp 2.2K-J,1/16W-1005REEL X2100E3 C20002226M101S 1
R1451 nsp 100K-J,1/16W-1005REEL X2100E3 C20001046M101S 1
R1457-1460 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 4
R1461 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1462 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1464 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1465 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1466 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1469 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1470-1477 nsp 33-J,1/16W-1005REEL C20003306M101S 8
R1478 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1479-1484 nsp 33-J,1/16W-1005REEL C20003306M101S 6
R1485 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1486 nsp 1.2K-J,1/16W-1005REEL C20001226M101S 1
R1487 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R1488 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1489 nsp 2.2M-J,1/16W-1005REEL C20002256M101S 1
R1490 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1491 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1492 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1493 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1494 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1495 nsp 47K-J,1/16W-1005REEL C20004736M101S 1
R1496 nsp 27K-J,1/16W-1005REEL C20002736M101S 1
R1497 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1498 nsp 220K-J,1/16W-1005REEL C20002246M101S 1
R1499 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1500 nsp 3.3K-J,1/16W-1005REEL C20003326M101S 1
R1501 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R1502,1503 nsp 10K-J,1/16W-1005REEL C20001036M111S 2
16

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
