Denon AVR-S900W Service Manual

HDMI
REF No. Part No. Part Name Remarks Q't
y
New
V
er
R1506 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1507,1508 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R1509 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1510 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1512 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1513-1516 nsp 33-J,1/16W-1005REEL C20003306M101S 4
R1517 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1518,1519 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 2
R1522 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1523 nsp 1M-J,1/16W-1005REEL C20001056M101S 1
R1524 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1533 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1544 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1545,1546 nsp 10K-J,1/16W-1005REEL C20001036M111S 2
R1547 nsp 47K-J,1/16W-1005REEL C20004736M101S 1
R1550 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1552 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R1553 nsp 2.2K-J,1/16W-1005REEL C20002226M101S 1
R1555,1556 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R1558 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1561 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1563,1564 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R1565 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1567-1570 nsp 10K-J,1/16W-1005REEL C20001036M111S 4
R1571 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R1573 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R1574 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R1575 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1576 nsp 4.7K-J,1/16W-1005REEL S900 C20004726M101S 1
R1578,1579 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R1580 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1581,1582 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R1583 nsp 4.7K-J,1/16W-1005REEL X2100 C20004726M101S 1
R1584 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1585 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1587 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1588 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1589 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1590 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1591 nsp 10-J 1/16W SMD(1005)*4 WA04X C180100042100S 1
R1593 nsp 10-J 1/16W SMD(1005)*4 WA04X C180100042100S 1
R1594 nsp 47-J,1/16W-1005REEL C20004706M101S 1
R1595 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1597 nsp 10-J 1/16W SMD(1005)*4 WA04X C180100042100S 1
R1599 nsp 10-J 1/16W SMD(1005)*4 WA04X C180100042100S 1
R1600 nsp 10K-J*4 1/16W SMD(1005) WA04 C180103042100S 1
R1601 nsp 2.2K-J,1/16W-1005REEL C20002226M101S 1
R1603 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R1604,1605 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R1606,1607 nsp 10K-J*4 1/16W SMD(1005) WA04 C180103042100S 2
R1608 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1610 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1612 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R1613,1614 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 2
R1615 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1617 nsp 10K-J*4 1/16W SMD(1005) WA04 C180103042100S 1
R1618 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1619 nsp 1M-J,1/16W-1005REEL C20001056M101S 1
R1620 nsp 10-J,1/16W-1005REEL C20001006M101S 1
R1621-1624 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 4
R1625 nsp 33-J,1/16W-1005REEL
C20003306M101S 1
R1626 nsp 220-J,1/16W-1005REEL C20002216M101S 1
R1627 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1630,1631 nsp 1.8K-J,1/16W-1005REEL C20001826M101S 2
R1632 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1633 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R1634 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1635 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R1637,1638 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 2
R1639 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R1640 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1641 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1642,1643 nsp 1K-D,1/16W-1608REEL C20001021M160S 2
R1644 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R1645 nsp 470-D,1/16W-1608REEL C20004711M160S 1
R1647 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R1651 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R1652 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1655 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R1657 nsp 0-J*2 1/16W SMD(1005) WA04Y C180000022100S 1
R1658 nsp 2.7K-F,1/16W-1608REEL C20002724M161S 1
R1659 nsp 180-F,1/16W-1608REEL C20001814M161S 1
R1660 nsp 2.7K-F,1/16W-1608REEL C20002724M161S 1
R1661 nsp 180-F,1/16W-1608REEL C20001814M161S 1
R1663-1665 nsp 0-J*2 1/16W SMD(1005) WA04Y C180000022100S 3
R1667-1669 nsp 33-J,1/16W-1005REEL C20003306M101S 3
R1671-1674 nsp 0-J,1/16W-1005REEL C20000006M101S 4
R1675 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1676,1677 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R1678 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1680 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1681 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1682 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1683 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1684 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R1685,1686 nsp 4.7K-J 1/16W SMD(1005)*4 WA04X C180472042100S 2
R1687 nsp 56-J,1/16W-1005REEL C20005606M101S 1
R1688,1689 nsp 47-J,1/16W-1005REEL C20004706M101S 2
R1690,1691 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 2
R1692 nsp 47-J 1/16W SMD(1005)*4 WA04X C180470042100S 1
R1693,1694 nsp 47-J,1/16W-1005REEL C20004706M101S 2
R1695-1700 nsp 47-J 1/16W SMD(1005)*4 WA04X C180470042100S 6
R1701,1702 nsp 47-J,1/16W-1005REEL C20004706M101S 2
R1703-1710 nsp 47-J 1/16W SMD(1005)*4 WA04X C180470042100S 8
R1711 nsp 47-J,1/16W-1005REEL C20004706M101S 1
R1715,1716 nsp 1K-D,1/16W-1608REEL C20001021M160S 2
17

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
