Denon AVR-S900W Service Manual

HDMI
REF No. Part No. Part Name Remarks Q't
y
New
V
er
R1717,1718 nsp 10K-J,1/16W-1005REEL C20001036M111S 2
R1731 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1732 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1733,1734 nsp 10K-J,1/16W-1005REEL C20001036M111S 2
R1735 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R1736 nsp 348K-F,1/16W-1608REEL C20034834M161S 1
R1737 nsp 300K-F,1/16W-1608REEL C20003044M160S 1
R1738 nsp 39K-F,1/16W-1608REEL C20003934M161S 1
R1739 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1740 nsp 10-J,1/16W-1005REEL C20001006M101S 1
R1741,1742 nsp 10K-J,1/16W-1005REEL C20001036M111S 2
R1743 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R1746 nsp 22K-J,1/16W-1005REEL C20002236M101S 1
R1747 nsp 39K-F,1/16W-1608REEL C20003934M161S 1
R1748 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R1750 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R1751 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1752 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R1753 nsp 348K-F,1/16W-1608REEL C20034834M161S 1
R1754 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1755 nsp 3.3K-J,1/16W-1005REEL C20003326M101S 1
R1756 nsp 47K-J,1/16W-1005REEL C20004736M101S 1
R1759 nsp 300K-F,1/16W-1608REEL C20003044M160S 1
R1760 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1761 nsp 10-J,1/16W-1005REEL C20001006M101S 1
R1762 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1763 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R1764 nsp 348K-F,1/16W-1608REEL C20034834M161S 1
R1765 nsp 412K-F,1/16W-1608REEL C20041234M161S 1
R1766 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1767 nsp 10-J,1/16W-1005REEL C20001006M101S 1
R1768 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1769 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R1770,1771 nsp 348K-F,1/16W-1608REEL C20034834M161S 2
R1772 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1773 nsp 10-J,1/16W-1005REEL C20001006M101S 1
R1774 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1775 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R1776-1778 nsp 10K-J,1/16W-1005REEL C20001036M111S 3
R1779 nsp 3.3K-J,1/16W-1005REEL C20003326M101S 1
R1780 nsp 348K-F,1/16W-1608REEL C20034834M161S 1
R1781 nsp 160K-F,1/16W-1608REEL C20001644M160S 1
R1782,1783 nsp 10K-J,1/16W-1005REEL C20001036M111S 2
R1784 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1785 nsp 10-J,1/16W-1005REEL C20001006M101S 1
R1786 nsp 2K-F,1/16W-1005REEL C20002024M100S 1
R1787 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R1788 nsp 348K-F,1/16W-1608REEL C20034834M161S 1
R1789 nsp 169K-F,1/16W-1608REEL C20016934M161S 1
R1790 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1791 nsp 3.3K-J,1/16W-1005REEL
C20003326M101S 1
R1793 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1794 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1795 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1796 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1797 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1798 nsp 39K-F,1/16W-1608REEL C20003934M161S 1
R1799 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R1800 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1801 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R1802 nsp 76.8K-F,1/16W-1608REEL C20076824M161S 1
R1803 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R1804 nsp 348K-F,1/16W-1608REEL C20034834M161S 1
R1806,1807 nsp 348K-F,1/16W-1608REEL C20034834M161S 2
R1808 nsp 169K-F,1/16W-1608REEL C20016934M161S 1
R1809 nsp 300K-F,1/16W-1608REEL C20003044M160S 1
R1810 nsp 10-J,1/16W-1005REEL C20001006M101S 1
R1811 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1812 nsp 10-J,1/16W-1005REEL C20001006M101S 1
R1813,1814 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 2
R1815 nsp 10-J,1/16W-1005REEL C20001006M101S 1
R1818,1819 nsp 10K-J,1/16W-1005REEL C20001036M111S 2
R1820,1821 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R1822 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1823 nsp 3.3K-J,1/16W-1005REEL C20003326M101S 1
R1824 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1825 nsp 0-J,1/16W-1005REEL X2100E3 C20000006M101S 1
R1827 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1828 nsp 348K-F,1/16W-1608REEL C20034834M161S 1
R1829 nsp 76.8K-F,1/16W-1608REEL C20076824M161S 1
R1830 nsp 10-J,1/16W-1005REEL C20001006M101S 1
R1831 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R1832 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1850-1852 nsp 47K-J,1/16W-1005REEL C20004736M101S 3
R1853-1855 nsp 10-J,1/16W-1005REEL C20001006M101S 3
R1856,1857 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R1858 nsp 10-J,1/16W-1005REEL C20001006M101S 1
R1859,1860 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R1861 nsp 10-J,1/16W-1005REEL C20001006M101S 1
R1862,1863 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R1864,1865 nsp 10-J,1/16W-1005REEL C20001006M101S 2
R1866 nsp 510-D,1/16W-1608REEL C20005111M161S 1
R1867 nsp 10-J,1/16W-1005REEL C20001006M101S 1
R1868 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1869,1870 nsp 1.8K-J,1/16W-1005REEL C20001826M101S 2
R1871 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1872 nsp 510-D,1/16W-1608REEL C20005111M161S 1
R1873-1880 nsp 0-J,1/16W-1005REEL C20000006M101S 8
R1881-1883 nsp 47-J,1/16W-1005REEL C20004706M101S 3
R1884 nsp 47K-J,1/16W-1005REEL C20004736M101S 1
R1885,1886 nsp 1.8K-J,1/16W-1005REEL C20001826M101S 2
R1887,1888 nsp 51-D,1/16W-1608REEL C20005101M160S 2
R1889,1890 nsp 10K-J,1/16W-1005REEL C20001036M111S 2
R1891 nsp 5.1-J,1/16W-1005REEL C2005R106M100S 1
R1892 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1893 nsp 1M-J,1/16W-1005REEL C20001056M101S 1
18

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
