Denon AVR-S900W Service Manual

HDMI
REF No. Part No. Part Name Remarks Q't
y
New
V
er
R1894 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R1897 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R1898 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1899 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R1900,1901 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 2
R1902 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1903 nsp 3.3K-J,1/16W-1005REEL C20003326M101S 1
R1905 nsp 820-J,1/16W-1005REEL C20008216M101S 1
R1906 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R1907 nsp 680-J,1/16W-1005REEL C20006816M101S 1
R1908 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R1909 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1910 nsp 10K-J*4 1/16W SMD(1005) WA04 C180103042100S 1
R1911 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1914,1915 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R1916,1917 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 2
R1919 nsp 0-J,1/16W-1608REEL C20000006M160S 1
R1920,1921 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R1922 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R1923 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1924 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R1925-1928 nsp 33-J,1/16W-1005REEL C20003306M101S 4
R1930-1933 nsp 33-J,1/16W-1005REEL C20003306M101S 4
R1934 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R1935-1942 nsp 33-J,1/16W-1005REEL C20003306M101S 8
R1943 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R1944,1945 nsp 10K-J,1/16W-1005REEL C20001036M111S 2
R1950 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1953-1955 nsp 10K-J,1/16W-1005REEL C20001036M111S 3
R1956 nsp 470-J,1/16W-1005REEL E3 C20004716M101S 1
R1957 nsp 47K-J,1/16W-1005REEL E3 C20004736M101S 1
R1958,1959 nsp 150-J,1/16W-1005REEL E3 C20001516M101S 2
R1960 nsp 330K-J,1/16W-1005REEL E3 C20003346M101S 1
R1961 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1963 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1965,1966 nsp 0-J,1/16W-1005REEL E2/E1/E1C/K C20000006M101S 2
R1967 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1969-1975 nsp 33-J,1/16W-1005REEL C20003306M101S 7
R1976-1980 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 5
R1981,1982 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R1983 nsp 5.1-J,1/16W-1005REEL C2005R106M100S 1
R1984-1986 nsp 0-J*2 1/16W SMD(1005) WA04Y C180000022100S 3
R1988-1990 nsp 0-J*2 1/16W SMD(1005) WA04Y C180000022100S 3
R1993,1994 nsp 1K-J,1/16W-1005REEL C20001026M101S 2
R1997,1998 nsp X7R)0.1UF-K/25V-1608REEL D011104774161S 2
R1999 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2002 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2010 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2013 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2017 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2020 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R2021 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2027,2028 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R2029 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R2032 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R2033 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R2034 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2037 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R2038 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2043 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R2044 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2047 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2049 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R2057 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R2058 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2061 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2062 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2066 nsp 470-J,1/16W-1005REEL C20004716M101S 1
R2067 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2068 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R2069 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2072 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2074 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R2078 nsp 470-J,1/16W-1005REEL C20004716M101S 1
R2082 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2085 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2089-2092 nsp 24-J,1/16W-1608REEL C20002406M160S 4
R2093-2096 nsp 51-J,1/16W-1608REEL C20005106M160S 4
R2097 nsp 2.2K-J,1/16W-1005REEL C20002226M101S 1
R2117 nsp 0-J,1/16W-1608REEL C20000006M160S 1
R2118 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2120 nsp 470-D,1/16W-1608REEL C20004711M160S 1
R2121 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2123,2124 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 2
R2125 nsp 4.7K-J 1/16W SMD(1005)*4 WA04X C180472042100S 1
R2126 nsp 47K-J,1/16W-1005REEL C20004736M101S 1
R2127 nsp 47-J,1/16W-1005REEL C20004706M101S 1
R2129 nsp 4.7K-J 1/16W SMD(1005)*4 WA04X C180472042100S 1
R2132 nsp 4.7K-J 1/16W SMD(1005)*4 WA04X C180472042100S 1
R2133 nsp 47K-J 1/16W SMD(1005)*4 WA04X C180473042100S 1
R2134 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R2135 nsp 4.7K-J 1/16W SMD(1005)*4 WA04X C180472042100S 1
R2136 nsp 47K-J 1/16W SMD(1005)*4 WA04X C180473042100S 1
R2137 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R2139 nsp 4.7K-J 1/16W SMD(1005)*4 WA04X C180472042100S 1
R2140,2141 nsp 47K-J,1/16W-1005REEL C20004736M101S 2
R2142 nsp 10-J 1/16W SMD(1005)*4 WA04X C180100042100S 1
R2143,2144 nsp 2.2K-J,1/16W-1005REEL C20002226M101S 2
R2146 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R2147 nsp 10-J,1/16W-1005REEL C20001006M101S 1
R2150 nsp 47K-J 1/16W SMD(1005)*4 WA04X C180473042100S 1
R2151 nsp 4.7K-J 1/16W SMD(1005)*4 WA04X C180472042100S 1
R2156 nsp 4.7K-J 1/16W SMD(1005)*4 WA04X C180472042100S 1
R2159 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R2162 nsp 47K-J,1/16W-1005REEL C20004736M101S 1
R2163 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
19

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
