Denon AVR-S900W Service Manual

HDMI
REF No. Part No. Part Name Remarks Q't
y
New
V
er
C2301-2303 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 3
C2304 nsp X7R)0.01UF-K/25V-1005REEL D011103174101S 1
C2305 nsp X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C2307 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C2308 nsp X7R)0.01UF-K/25V-1005REEL D011103174101S 1
C2309 nsp X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C2311,2312 nsp X7R)4.7UF-K/6.3V-1608REEL D011475571160S 2
C2320 nsp X7R)0.1UF-K/25V-1608REEL D011104774161S 1
C2322 nsp COG8PF-D/50V-1608REEL D010080117160S 1
C2323 nsp COG7PF-D/50V-1608REEL D010070117160S 1
C2325 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C2327 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C2340 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 1
C2341 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C6000 nsp COG)27PF-J/50V-1005REEL D011270167101S 1
C6001 nsp COG)22PF-J/50V-1005REEL D011220167101S 1
C6002 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 1
C6003,6004 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 2
C6005,6006 nsp X7R)1UF-K/6.3V-1005REEL D011105771100S 2
C6007 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
OTHER PARTS GROUP
★ ns
p
MINI JUMPER 2.00MM L424010280210S 1
★ ns
p
A
VRS900WBKE3 SPCC t0.8 Sn-Platin
g
A4/HDMI FRONT 4010215996000S 1
CLP1000-1002 nsp HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 3
CP6001 nsp 460MM/11P 20010HS-11=CKM2002HR-11 RD2725#24,28 SHL L002461110010S 1
K1000,1001 00D9630244703 EARPHONE JACK PJ-308-02 X2100E3 G40130802000YS 2
K1003 963643003580S RCA-107C-02(OR) E3 G600107C0020YS 1
L1000-1013 nsp CB05YTYH221-2012REEL D340201292210S 14
L1016 nsp CB05YTYH221-2012REEL D340201292210S 1
L1017,1018 nsp DLW21SN900HQ2L COMMON MODE CHOKE COILS SMD2012 D311201219000S 2
L1019 nsp CB05YTYH221-2012REEL D340201292210S 1
L1027-1030 nsp 0-J,1/10W-2012REEL C200000060200S 4
L1034-1036 nsp 0-J,1/10W-2012REEL C200000060200S 3
L1037-1049 nsp CB05YTYH221-2012REEL D340201292210S 13
L1051-1057 nsp CB05YTYH221-2012REEL D340201292210S 7
L1058 nsp CB03YTYN121-1608REEL D340160891210S 1
L1059-1077 nsp CB05YTYH221-2012REEL D340201292210S 19
L1080-1088 nsp CB05YTYH221-2012REEL D340201292210S 9
L1089 nsp CB03YTYN121-1608REEL D340160891210S 1
L1090-1106 nsp CB05YTYH221-2012REEL D340201292210S 17
L1109-1115 nsp CB05YTYH221-2012REEL D340201292210S 7
L1119 nsp EXC24CH900U 90OHM COMMON MODE SMD-REEL D311121089000S 1
L1123 nsp EXC24CH900U 90OHM COMMON MODE SMD-REEL D311121089000S 1
L1124-1127 nsp CB05YTYH221-2012REEL D340201292210S 4
L1136 nsp 0-J,1/10W-2012REEL C200000060200S 1
L6000,6001 nsp CB05YTYH221-2012REEL D340201292210S 2
L6002 nsp 0-J,1/10W-2012REEL C200000060200S 1
N1000 nsp 1.0-16-23PB-2 23P ST SMT (JSY) L130100162330S 1
N1001-1007 963643102850S HD 19F SMT-028 19P SMT HDMICON WITH FLANGE L109100190280S 7 *
N1009 nsp 1.0-16-7PB-2 7P ST SMT (JSY) L130100160730S 1
N1010 963643102800S RJ45-JACK(KRJ-015XXNL) KYD G4060RJ450230S 1 *
N1011 nsp 1.0-16-7PB-2 7P ST SMT (JSY) L130100160730S 1
N1013 nsp C125Z2-07 7P BtoB SOCKET(FEMALE) P=1.25MM L109012520740S 1 *
N1014 nsp C125Z2-23 23P BtoB SOCKET(FEMALE) P=1.25MM L109012522340S 1 *
N1015 nsp C125Z2-15 15P BtoB SOCKET(FEMALE) P=1.25MM L109012521540S 1 *
N1016 nsp C125Z2-23 23P BtoB SOCKET(FEMALE) P=1.25MM L109012522340S 1 *
N1017 nsp 1.0-15-40PB 40P VER SMT L130100154030S 1
N1018 nsp C125Z2-17 17P BtoB SOCKET(FEMALE) P=1.25MM L109012521740S 1 *
N1019 nsp 20010WS-07A00 DIP7P STRAIGHT L101200100710S 1
N1021 nsp 1.0-16-11PB-2 11P ST SMT (JSY) L130100161130S 1
N1025 nsp 1.0-16-11PB-2 11P ST SMT (JSY) L130100161130S 1
N1026 963643102860S HD 19F SMT-029 19P SMT HDMICON W/O FLANGE L109100190290S 1 *
N1027 nsp 1.0-16-10PB-2 10P ST SMT (JSY) L130100161030S 1
N1028 nsp 1.0-16-7PB-2 7P ST SMT (JSY) L130100160730S 1
N1029 nsp SMW250-5P DIP ST L102050010040S 1
N1030,1031 963643102850S HD 19F SMT-028 19P SMT HDMICON WITH FLANGE L109100190280S 2 *
N1032 nsp 1.0-16-7PB-2 7P ST SMT (JSY) L130100160730S 1
N1033 nsp C125Z2-11 11P BtoB SOCKET(FEMALE) P=1.25MM L109012521140S 1 *
N1034 nsp 1.0-16-6PB-2 6P ST SMT (JSY) L130100160630S 1
N1035 nsp 1.0-16-7PB-2 7P ST SMT (JSY) L130100160730S 1
N1036 nsp 20010WS-04A00 DIP4P STRAIGHT L101200100410S 1
N1038 nsp 1.0-16-23PB-2 23P ST SMT (JSY) L130100162330S 1
SW1 nsp C12001-2020-03G-2537 HEADER P=2.0MM L101012000310S 1
X1000,1001 963141101180S 27.000MHz CL=7PF FA-238/SMD3225 EPSON E80527R000050S 2 *
X1003,1004 963141101160S 12.000MHz CL=8PF FA-238V/SMD3225 EPSON E80512R000260S 2 *
X1005 963141101170S 21.875MHz CL=8PF FA-238/SMD3225 EPSON E80521R875260S 1 *
X1006,1007 963141101180S 27.000MHz CL=7PF FA-238/SMD3225 EPSON E80527R000050S 2 *
X1008 963141100770S 24.576MHz CL=10PF FA-238/SMD3225 EPSON E80524R576050S 1
X1009 963141101180S 27.000MHz CL=7PF FA-238/SMD3225 EPSON E80527R000050S 1 *
X6000 963141101190S 32.768KHz CL=12.5PF FC-135/SMD3215 EPSON E80532R768260S 1 *
24

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
