Denon AVR-S900W Service Manual

CX870_MIDDLE
CX870
_
MIDDLE PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model K : Japan model
BK : Black model SP : Silver gold model
REF No. Part No. Part Name Remarks Q't
y
New
V
er
SEMICONDUCTORS GROUP
U7000 963239101360S BD82065FVJ CURRENT LIMIT 2.4A TSSOP-B8J J046820650010S 1 *
RESISTOR GROUP
R7002,7003 nsp 0-J,1/10W-2012REEL C200000060200S 2
R7004 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R7006,7007 nsp 0J*4 1/16W SMD(1005) C180000040500S 2
R7008,7009 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R7010 nsp 0J*4 1/16W SMD(1005) C180000040500S 1
R7011-7013 nsp 0-J,1/16W-1005REEL C20000006M101S 3
R7014 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R7015 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R7016 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R7021 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R7025-7027 nsp 0-J,1/16W-1005REEL C20000006M101S 3
R7028-7035 nsp 0-J,1/16W-1608REEL C20000006M160S 8
R7036,7037 nsp 2.2K-J,1/16W-1005REEL C20002226M101S 2
R7038 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R7041 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R7048-7052 nsp 0-J,1/16W-1005REEL C20000006M101S 5
CAPACIITORS GROUP
C7000 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C7005 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C7006-7010 nsp X7R)10UF-K/6.3V-2012REEL D011106771201S 5
C7013,7014 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 2
C7015,7016 nsp X7R)1UF-K/10V-1608REEL D011105772161S 2
OTHER PARTS GROUP
BKT7000,7001 nsp AVRX2100BKE3 SPCC t0.5 Sn-Plating A4/SCREW L4.5 4010216006000S 2
CLP7000 nsp HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 1
L7000,7001 nsp CB05YTYH221-2012REEL D340201292210S 2
N7000 nsp 160MM/4P 20010HS-04=CKM2002HR-04 WH1007#26 L002161042630S 1
N7001 nsp 14-5046-120-645-829+ BD TO BD CON 120P WITH TAPE L136504601260S 1
N7002 nsp 20010WR-05A00 DIP5P RIGHT ANGLE L101200100520S 1
N7003,7004 nsp FEMALE HEADER 1.27MM 32*2P CSEC202-3202 B001 C1 AF L109020232020S 2
N7005 nsp 20010WR-11A00 DIP11P RIGHT ANGLE L101200101120S 1
25

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
