Input

CVBS

Check the set value of each

IC. Are the voltage values as

follows?

HDMI PCB

N1018 - 3pin : Hi(3.3V)

N1018 - 4pin : Hi(3.3V)

N1018 - 5pin : Lo(0V)

Is the power supply voltage

being output correctly?

V+5V : C5029 : + side

V-5V : C5031 : - side

Is a signal being output from

the video amplier?

CVBS : J5039

The circuit between IC5001

and JACK5000 are faulty.

•Check the IC5001 power supply

voltage and check the soldering of

the surrounding circuits.

•The circuit between IC5001 and

JACK5000 are faulty.

Use the jigs to extend the

HDMI PCB.

The HDMI PCB is faulty.

Check the connection between the

FRONT CONNECTOR PCB and the

VIDEO PCB.

YES

All parts are VIDEO PCB parts unless otherwise specied.
