Input

COMPONENT

Check the set value of each

IC. Are the voltage values as

follows?

HDMI PCB

N1018 - 2pin : Lo(0V)

N1018 - 6pin : Hi(3.3V)

Is the power supply voltage

being output correctly?

V+5V : C5029 : + side

V-5V : C5031 : - side

Is a signal being output from

the video amplier?

COMP-Y : J5032

COMP-CB : J5033

COMP-CR : J5000

The circuit between IC5002

and JACK5000 are faulty.

Use the jigs to extend the

HDMI PCB.

The HDMI PCB is faulty.

Check the connection between the

FRONT CONNECTOR PCB and the

VIDEO PCB.

YES

All parts are VIDEO PCB parts unless otherwise specied.

•Check the IC5001 power supply voltage and check the soldering of the surround-

ing circuits.

•The circuit between IC5002 and JACK5000 are faulty.

•Check the cable between the unit and the player, and check the player itself.
