Denon AVR-X2000 Service Manual

Types of input signals, and corresponding sound modes This table shows the input signal that can be played in each sound mode. Check the audio signal of the input source then select the sound mode. Symbols in the table F
This indicates the default sound mode.
S
This indicates the selectable sound mode.
Sound Mode NOTE
Input signal types and formats
ANALOG
PCM DTS-HD DTS DOLBY DOLBY DIGITAL
PCM
(Multi-
channel)
PCM
(2-channel)
DTS-HD
Master
Audio
DTS-
HD High
Resolution
Audio
DTS
EXPRESS
DTS ES
DSCRT
(With Flag)
DTS ES
MTRX
(With Flag)
DTS
(5.1-channel)
DTS 96/24
DOLBY
TrueHD
DOLBY
DIGITAL
Plus
DOLBY
DIGITAL
EX (With
Flag)
DOLBY
DIGITAL
EX (With
no Flag)
DOLBY
DIGITAL
(5.1-channel)
DOLBY
DIGITAL
(2-channel)
DTS SURROUND
DTS-HD MSTR
F
DTS-HD HI RES
F
DTS ES DSCRT6.1
z
1
z
2
F
DTS ES MTRX6.1
z
1
z
2
F
DTS SURROUND
S S F
DTS 96/24
F
DTS (–HD) + PL
g
x CINEMA
z
1
z
3
S S S S S
DTS (–HD) + PL
g
x MUSIC
z
1
z
2
S S S S S
DTS (–HD) + PL
g
z
z
1
z
4
S S S S S S S
DTS EXPRESS
F
DTS (–HD) + NEO:6
z
1
z
2
S S S S S
DTS NEO:6 CINEMA
S S S
DTS NEO:6 MUSIC
S S S
DOLBY SURROUND
DOLBY TrueHD
F
DOLBY DIGITAL+
F
DOLBY DIGITAL EX
z
1
z
2
S S S
DOLBY (D+) (HD) +EX
z
1
z
2
S S
DOLBY DIGITAL
S F F
DOLBY (D) (D+) (HD) +PL
g
x
CINEMA
z
1
z
3
S S F S S
DOLBY (D) (D+) (HD) +PL
g
x
MUSIC
z
1
z
2
S S S S S
DOLBY (D) (D+) (HD) +PL
g
z
z
4
S S S S S
DOLBY PRO LOGIC
g
x CINEMA
z
1
z
2
S S S
DOLBY PRO LOGIC
g
x MUSIC
z
1
z
2
S S S
DOLBY PRO LOGIC
g
x GAME
z
1
z
2
S S S
DOLBY PRO LOGIC
g
z
z
1
z
4
S S S
DOLBY PRO LOGIC
g
CINEMA
S S S
DOLBY PRO LOGIC
g
MUSIC
S S S
DOLBY PRO LOGIC
g
GAME
S S S
z
1 This sound mode can be selected when “Amp Assign” is set to “Surround Back”.
z
2 If “Speaker Cong.” – “Surr. Back” is set to “None”, this sound mode cannot be selected.
z
3 If “Speaker Cong.” – “Surr. Back” is set to “1spkr” or “None”, this sound mode cannot be selected.
z
4 If “Speaker Cong.” – “Front Height” is set to “None”, this sound mode cannot be selected.
77

Denon AVR-X2000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	7
AC (power) in	Yes
Audio (L/R) in	4
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS-ES, DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	330 mm
Width	434 mm
Height	167 mm
Weight	9500 g
