Denon AVR-X2400H Service Manual

4. Protection Pass Mode 5. Network Initialization Mode
4.1. Actions
• This mode allows the power to be turned on without activating protections.
• This mode functions in the same way as normal power-on, except that protections are not activated.
• When using the protection pass mode, do not connect speakers to the speaker terminals.
4.2. Operations
AVR-X2400H
· While holding down buttons "
TUNER PRESET CH +
", "
ZONE2 SOURCE
" and "
STATUS
" simultane-
ously, press the power button to turn on the power.
AVR-S930H
· While holding down buttons "
ZONE2 SOURCE
", "
TUNER PRESET CH +
" and "
TUNE +
" simultane-
ously, press the power button to turn on the power.
The device returns to the normal display message after the following is displayed.
Protection Pass
This is displayed for 5 seconds before returning to the normal display.
5.1. Actions
The following items are initialized.
(1) Network setup
(2) Friendly Name
(3) Auto Update setting
(4) Allow Update setting
(5) Time Zone setting
(6) Queue list
(7) Internet Radio recently played station
(8) Quick Select playback station
(9) AirPlay Password
(10) Bluetooth Pairing History
5.2. Operations
AVR-X2400H
· When the power is on and the input source is HEOS Music, press and hold the "
TUNERPRESET CH
+
" and "
ZONE2ON/OFF
" buttons for more than 3 seconds.
AVR-S930H
· When the power is on and the input source is HEOS Music, press and hold the "
ZONE2 SOURCE
" and
"
ZONE2ON/OFF
" buttons for more than 3 seconds.
Initializing Display
L1
Network Reset...
Complete Display
L1
Completed
This is displayed for 5 seconds before returning to the normal display.
133
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon AVR-X2400H Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Pre-out channels	2 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	95 W
Display	VFL
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround
Volume control	Rotary
Center speaker impedance	16 Ω
Supported video modes	720i, 720p, 960p, 1080i, 1080p, 2160p
Supported graphics resolutions	3840 x 2160
HDMI in	8
Audio (L/R) in	4
Digital audio coaxial in	0
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Deezer, Napster, Pandora, SIRIUS Internet Radio, Spotify, Tidal, iHeartRadio
Audio formats supported	ALAC, DSD, FLAC, MP3, WAV
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	3.5mm
Certification	CE, EAC

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	167 mm
Weight	9400 g
