Denon AVR-X2400H Service Manual

FIRMWARE UPDATE PROCEDURE
1. Items necessary for update
Items necessary for update are as follows.
Update Type Needed Part for Update Requirement
Offered / not Offered
Standard Service Equipment
Not offered by D&M
Purchase from D&M Article code Download from SDI
Via USB
USB ash drive (USB 2.0 : Min 1GB)
• We recommend a USB memory device
that has an LED installed.
Formatting FAT16 or FAT 32 X - "Table 1" or "Table 2"
Via OTA
Internet Connection by Broadband Circuit - X - -
Modem - X - -
Router - X - -
Ethernet cable
(CAT-5 or greater is recommended)
- X - -
Table 1
Update download le when the DIGITAL PCB or network module is replaced
Model Name Model Area Download from SDI
AVR-X2400H ALL avr_40.prod.update.factory.xxxx.zip
Table 2
Update download le when the rmware is updated (Two les, "HW component" and "LEGO component")
Model Name Model Area
Download from SDI
For HW component For LEGO component
AVR-X2400HE3 North America (E3) Product ID : 000100980100
DPMS_AVR-X2400HALL_LEGO_xxxx.zip
heos_40.prod_x.xxx.xx.zip
AVR-X2400HE2 Europe (E2) Product ID : 000100980200
AVR-X2400HJP Japan (JP) Product ID : 000100980400
AVR-X2400HE1C China (E1C) Product ID : 000100980500
AVR-S930HE3 North America (E3) Product ID : 000100980700 DPMS_AVR-S930HE3_LEGO_xxxx.zip
161
Caution in
servicing
Electrical Mechanical Repair Information Updating
