Denon AVR-X2400H Service Manual

5. Network / Bluetooth / USB
Check the setting
Are the network settings of this unit correct?
Are peripheral devices such as the router and hub
connected to this unit correctly?
Are the router settings correct?
Set the IP address, etc. correctly.
When the static IP address is used, check that no
other devices have the same IP address and that
the subnet mask settings are correct.
Connect the peripheral devices correctly.
Check the instruction manual of the router and
congure the settings correctly.
Check that there are no connection restrictions by
MAC addresses, etc.
5.1. Cannot connect to the network
Is the LAN cable correctly inserted?
Insert the LAN cable correctly and then turn on
the power again.
Check the connection environment
Checking the unit
Can the output voltage (5V) to
[Q1074 : FET-SW] be conrmed?
Can the voltage (5V) be conrmed between
[N1033 : 2-5pin]?
Is NET5V POWER [U1018 : 48pin
uCOM ] "Hi" ?
The circuit of NET5V POWER
between [U1018-Q1074 : FET-
SW] are faulty.
The circuit around [Q1074 : FET-
SW] is faulty.
The circuit between the AC inlet and [N1033] is
faulty.
Check the SMPS PCB.
Can the output voltage (3.3V)
to [U1067 : DC-DC Conv.] be
conrmed?
Can the output voltage (3.3 V)
to [Q1071 : FET-SW] be con-
rmed?
Is D5V_POWER [U1018 :136 pin
uCOM] "Hi" ?
Is NET3.3V POWER [U1018 : 135
pin uCOM] "Hi" ?
The circuit of D5V_POWER
between [U1018-U1067] are
faulty.
The circuit of NET3.3V POWER
between [U1018-Q1071] are
faulty.
The circuit around [U1067 : DC-
DC.Conv.] is faulty.
The circuit around [Q1071 : FET-
SW] is faulty.
Go to next page.
YES
YES
YES
YES
YES
NO NO
NO
NO
NO
NO
NO
YES
YES
YES
NO
NO
NO
NO
YES
YES
YES
80
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon AVR-X2400H Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Pre-out channels	2 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	95 W
Display	VFL
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround
Volume control	Rotary
Center speaker impedance	16 Ω
Supported video modes	720i, 720p, 960p, 1080i, 1080p, 2160p
Supported graphics resolutions	3840 x 2160
HDMI in	8
Audio (L/R) in	4
Digital audio coaxial in	0
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Deezer, Napster, Pandora, SIRIUS Internet Radio, Spotify, Tidal, iHeartRadio
Audio formats supported	ALAC, DSD, FLAC, MP3, WAV
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	3.5mm
Certification	CE, EAC

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	167 mm
Weight	9400 g
