Denon AVR-X2400H Service Manual

SUBWOOFER ch
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
AVR-S930H/X2400H
LEVEL DIAGRAM
SUBWOOFER ch
-
2
.0-
0
.5+
1
4=11.
5
dB
+30dB
-
2
.0-
0.5+
1
4+
3=
+1
4.
5
d
B
MA
X
SIGN
A
L L
E
VEL
D
OLB
Y
LI
M
IT LE
V
EL (
A
LL
c
h-3
d
B
F
S)
0dBFS
-10dBFS
-20dBFS
-30dBFS
-40dBFS
AK4458
NJU72343 MAX. OUTPUT 4.2Vrms
＋
SPEAKER
OUT
D
SP
GAIN
ADJ.
P
LD
NJU72343
PREOUT
PREOUT
150mVrms
-40dBFS(DIG.IN)
DD Config1
INPUT:-30dBFS DD LFE
-34dBFS(PCM.IN)
-37dBFS(A/D IN)
INPUT : -20dBFS(DIG.IN) PCM
200mV(A/D IN)
+6.5dB
MGAIN setting of MASTER VOL 00dB
･DOLBY DIGITAL IN -2.0dB - 0.5dB + 14dB =+11.5dB
･PCM DIGITAL IN -2.0dB - 0.5dB + 14dB =+11.5dB
･ANALOG IN -2.0dB + 14dB + 3.0dB = + 15.0dB
① ②③④
①:Basic OFFSET of VOL=0dB
②:Fine-tuning by Digital input
③:OFFSET of SW-ch
④:OFFSET of A/D input
-
2
.
0-0
.
5+1
4
=
1
1
.
5
d
B
PREOUT
300mVrms
0dBFS = +/-2.8Vpp=1.98Vrms
＋
－
AK4458VN
D/A
－
＋
46
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon AVR-X2400H Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Pre-out channels	2 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	95 W
Display	VFL
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround
Volume control	Rotary
Center speaker impedance	16 Ω
Supported video modes	720i, 720p, 960p, 1080i, 1080p, 2160p
Supported graphics resolutions	3840 x 2160
HDMI in	8
Audio (L/R) in	4
Digital audio coaxial in	0
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Deezer, Napster, Pandora, SIRIUS Internet Radio, Spotify, Tidal, iHeartRadio
Audio formats supported	ALAC, DSD, FLAC, MP3, WAV
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	3.5mm
Certification	CE, EAC

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	167 mm
Weight	9400 g
