Denon AVR-X4100W

Pin Symbol Pin Name I/O Pu/Pd LvCnv STBY
CEC
STBY
Function
35 PH3 HSDA
I/O C
CEC
3VPu
O/L L
HDMI I2C- MN8647781
36 PH2/IRQ1 HSCL
I/O C
CEC
3VPu
O/L L
HDMI I2C- MN8647781
37 PH1/IRQ0 778_1_HINT
I - - Z -
HDMI MN8647781(TX) HDMI INT input pin
38 PH0 778_2_RST
O C Pd Z ※
HDMI MN8647781(RX) RESET control pin
39 P55 778_2_HINT
I - - Z -
HDMI MN8647781(RX) HDMI INT input pin
40 P54 778_3_RST
O C Pd Z ※
HDMI MN8647781(RX) RESET control pin
41 BCLK/P53 778_3_HINT
I - - Z -
HDMI MN8647781(RX) HDMI INT input pin
42 P52 IP_RST
O C Pd Z L
HDMI ADV8003 RESET control pin
43 P51 DE_RST
O C Pd Z L
HDMI ADV7850 RESET control pin
44 P50 DE_INT
I - - Z -
HDMI ADV7850 HDMI INT input pin
45 PC7/TXD8/SSDA8 UB
I - Pd Z -
Unused
46 PC6/RXD8/SSCL8 HINSELA
O C - Z -
TC74VHC4051AFT control pin. (Control the detection
of HDMI 5V INPUT for CEC STANDBY. )
47 PC5/SCK8 HINSELB
O C - Z -
TC74VHC4051AFT control pin. (Control the detection
of HDMI 5V INPUT for CEC STANDBY. )
48 PC4/SCK5 HINSELC
O C - Z -
TC74VHC4051AFT control pin. (Control the detection
of HDMI 5V INPUT for CEC STANDBY. )
49 PC3/TXD5/SSDA5 DSPMOSI
O C
DA3
VPu
Z L
DSP control pin (ADSP21487KSWZ-3B)
50 PC2/RXD5/SSCL5 DSPMISO
I -
DA3
VPu
Z -
DSP control pin (ADSP21487KSWZ-3B)
51 PC1/SCK5 DSPICLK
O C
DA3
VPu
Z L
DSP control pin (ADSP21487KSWZ-3B)
52 PC0 DA_POWER
O C - Z L
DIGITAL AUDIO POWER SUPPLY (DA3.3V & DA1.1V)
control pin.(ON:H)
53 PB7/TXD9/SSDA9 AVSDA
I/O C
DV3
VPu
O/L L
VIDEO I2C- ADV8003/ADV7850
54 PB6/RXD9/SSCL9 AVSCL
I/O C
DV3
VPu
O/L L
VIDEO I2C- ADV8003/ADV7850
55 PB5/SCK9 CEC_POWER
O C - Z ※
HDMI CEC POWER SUPPLY control pin
(CEC5V,CEC3.3V,CEC1.8V)
56 PB4 DV_POWER1
O C - Z L
Digital VIDEO POWER SUPPLY control pin
(DV5V,DV3.3V)
57 PB3/SCK8 DV_POWER2
O C - Z -
Digital VIDEO POWER SUPPLY control pin (DV1.8V)
58 PB2 H5VDET
I - - Z -
HDMI INPUT 5V (for EDID / HOT PLUG) detection pin
59
PB1/TXD6/SSDA6/IRQ4-
DS
778_3_HAINT
I - - Z -
HDMI MN8647781(RX) Audio INT input pin
60 VCC VCC
- - - - -
+3.3V
61 PB0/RXD6/SSCL6 NC
O C - Z -
NC
62 VSS VSS
- - - - -
GND
63 PA7 HPD8
O C - Z L
HPD8 output pin
64 PA6 HPD7
O C - Z L
HPD7 output pin
65 PA5 HPD6
O C - Z L
HPD6 output pin
66
PA4/TXD5/SSDA5/IRQ5-
DS
HPD5
O C - Z L
HPD5 output pin
67
PA3/RXD5/SSCL5/IRQ6-
DS
HPD4
O C - Z L
HPD4 output pin
68 PA2/RXD5/SSCL5 HPD3
O C - Z L
HPD3 output pin
69 PA1/SCK5 HPD2
O C - Z L
HPD2 output pin
70 PA0 HPD1
O C - Z L
HPD1 output pin
71 PE7/IRQ7/AN015 APLDCK
O C - Z L
A.PLD control pin
72 PE6/IRQ6/AN014 APLDCS
O C - O/L L
A.PLD control pin
73 PE5/IRQ5/AN013 APLDDI
O C - Z L
A.PLD control pin
74 PE4/AN012 SUB_TCK
O C Pd Z L
A.PLD/V.PLD rewriting pin(JTAG)
75 PE3/AN011 SUB_TDI
O C
DA
3.3Pu
Z L
A.PLD/V.PLD rewriting pin(JTAG)
76
PE2/RXD12/SSCL12/IRQ7-
DS/AN010
SUB_TDO
I - - Z L
A.PLD/V.PLD rewriting pin(JTAG)
77
PE1/TXD12/SSDA12/
AN009
SUB_TMS
O C
DA
3.3Pu
Z L
A.PLD/V.PLD rewriting pin(JTAG)
78 PE0/SCK12/AN008 DACRST1
O C - Z L
D/A converter control pin(PCM1690)
79 PD7/IRQ7 NC
O C - Z -
NC
80 PD6/IRQ6 DACMC
O C - Z L
D/A converter control pin(PCM1690)
81 PD5/IRQ5 DACMD
O C - Z L
D/A converter control pin(PCM1690)
82 PD4/IRQ4 DACMS1
O C - Z L
D/A converter control pin(PCM1690)
83 PD3/IQR3 NC
O C - Z -
NC
84 PD2/IRQ2 DSP1RST
O C - Z L
DSP(ADSP21487KSWZ-3B) reset output pin (Reset : L)
181
