Denon AVR-X4100W

VIDEO
V
IDEO PCB ASS'
Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D5161 00D2760718902 DIODE,SCHOTTKY,30V CVDRB521S-30 1
D5211 943202500740D DIODE,ZENER(16V/0.5W,SOD-123) CVDMM1Z16H 1
D5221 943202500740D DIODE,ZENER(16V/0.5W,SOD-123) CVDMM1Z16H 1
D5251 00D2760718902 DIODE,SCHOTTKY,30V CVDRB521S-30 1
D5252 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 1
D5254 00D2760718902 DIODE,SCHOTTKY,30V CVDRB521S-30 1
IC511 235810046603S I.C,MULTIINPUTVIDEO CVIAVDM2000 1
IC513 943239010400S I.C,REGULATOR(3.3V/TO-252) CVINJM2845DL133 1
IC521 963239008800S I.C,RS232(3.3V) CVIILX3232DT 1
Q5211 943212500220D T.R,2SA2166,PNP,TO-236,ISAHAYA CVT2SA2166 1
Q5212 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q5221 943212500220D T.R,2SA2166,PNP,TO-236,ISAHAYA CVT2SA2166 1
Q5222 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q5251 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C 1
Q5252 943214500020S T.R,2SC3052 CVT2SC3052 1
RESISTOR GROUP
R5101-5103 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 3
R5104 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R5107 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5109 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5110 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R5111 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5112 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R5121-5126 nsp RES,CHIP(1608/1%/150ohm) CRJ10DF1500T 6
R5131-5136 nsp RES,CHIP(1608/1%/150ohm) CRJ10DF1500T 6
R5157-5159 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 3
R5171,5172 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R5173,5174 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R5175 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5176 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R5177 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5178 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R5179 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5180,5181 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 2
R5183-5186 nsp RES,CHIP(1608/5%/10ohm) CRJ10DJ100T 4
R5187-5189 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 3
R5190 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R5193 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5194 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R5211 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R5212 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R5221 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R5222 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R5223,5224 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R5231-5234 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 4
R5251 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R5252 nsp RES,CHIP(1608/5%/3.3Kohm) CRJ10DJ332T 1
R5253 nsp RES,CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R5254 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
CAPACIITORS GROUP
C5107-5109 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 3
C5121-5123 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 3
C5131-5133 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 3
C5161 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C5162 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C5163 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C5164 nsp CAP,ELECT(16V/47uF) CCEA1CH470T 1
C5165,5166 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 2
C5171 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C5174-5176 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 3
C5178-5181 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 4
C5182,5183 nsp CAP,ELECT(16V/47uF) CCEA1CH470T 2
C5184-5192 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 9
C5193 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C5194 nsp WIRE,COPPER(D0.6) C3A206 0.02
C5212,5213 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 2
C5214 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG CCUS1H102KCS 1
C5222,5223 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 2
C5224 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG CCUS1H102KCS 1
C5231 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C5233-5235 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 3
C5236 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C5237 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C5238,5239 nsp CAP,CHIP(1608,50V/33pF,C0G)_SAMSUNG CCUS1H330JAS 2
C5251 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG CCUS1H102KCS 1
C5252 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C5253 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG CCUS1H102KCS 1
OTHER PARTS GROUP
BN21B nsp PINSOCKET(19P,1.25mm,ANGLE,B-TO-B) CJP19HJ282Z 1
BN27B nsp PINSOCKET(19P,1.25mm,ANGLE,B-TO-B) CJP19HJ282Z 1
BN28B nsp PINSOCKET(13P,1.25mm,ANGLE,B-TO-B) CJP13HJ282Z 1
JK511 943643102990S JACK,RCA5P(Y/Y/Y/Y/Y)SILVER CJJ4T001Z 1 *
JK512 943643101910S JACK,6P(G/G,B/B,R/R),SILVER CJJ4R054Z 1
JK513 943643101100S JACK,3P(G/B/R),SILVER CJJ4S050Z 1
JK521 943646100420S JACK,9PD-SUBFEMALE(RS-232C) CJJ9W001Z 1
JK522,523 643010086019S JACK,STEREO(REDMOLD) CJJ2D019Z 2
JK525,526 90M-YT004860R JACK,STEREO(BLKMOLD) CJJ2D008Z 2
JW501 nsp WIREASS'Y(1P,80MM,BLK,#22) CWE5202080A 1
