Denon AVR-X4100W

7CHAMP
7CHAMP PCB ASS'
Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D7108,7109 00D9430182609 DIODE,SWITCHING CVD1SS133MT 2
D7118 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D7139 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D7208,7209 00D9430182609 DIODE,SWITCHING CVD1SS133MT 2
D7218 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D7239 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D7308,7309 00D9430182609 DIODE,SWITCHING CVD1SS133MT 2
D7318 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D7339 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D7408,7409 00D9430182609 DIODE,SWITCHING CVD1SS133MT 2
D7418 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D7439 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D7508,7509 00D9430182609 DIODE,SWITCHING CVD1SS133MT 2
D7518 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D7539 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D7608,7609 00D9430182609 DIODE,SWITCHING CVD1SS133MT 2
D7618 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D7639 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D7708,7709 00D9430182609 DIODE,SWITCHING CVD1SS133MT 2
D7718 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D7739 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
Q7001 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q7104 21785000550AS T.R,PNP,DUAL,HN4A06J,SOT-25,TOSHIBA CVTHN4A06J 1
Q7114 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q7118 00D2710314903 T.R HVTKTA1024YT 1
Q7120,7121 00D2730471907 T.R HVTKTC3206YAT 2
Q7125 963219003340S T.R,BIAS CVTKTC3964 1
Q7131 00D9630235301 T.R,POWER(Pc130W) HVT2SD2560 1
Q7132 00D9630235204 T.R,POWER(Pc130W) HVT2SB1647 1
Q7138 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q7139 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551 1
Q7204 21785000550AS T.R,PNP,DUAL,HN4A06J,SOT-25,TOSHIBA CVTHN4A06J 1
Q7214 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q7218 00D2710314903 T.R HVTKTA1024YT 1
Q7220,7221 00D2730471907 T.R HVTKTC3206YAT 2
Q7225 963219003340S T.R,BIAS CVTKTC3964 1
Q7231 00D9630235301 T.R,POWER(Pc130W) HVT2SD2560 1
Q7232 00D9630235204 T.R,POWER(Pc130W) HVT2SB1647 1
Q7238 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q7239 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551 1
Q7304 21785000550AS T.R,PNP,DUAL,HN4A06J,SOT-25,TOSHIBA CVTHN4A06J 1
Q7314 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q7318 00D2710314903 T.R HVTKTA1024YT 1
Q7320,7321 00D2730471907 T.R HVTKTC3206YAT 2
Q7325 963219003340S T.R,BIAS CVTKTC3964 1
Q7331 00D9630235301 T.R,POWER(Pc130W) HVT2SD2560 1
Q7332 00D9630235204 T.R,POWER(Pc130W) HVT2SB1647 1
Q7338 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q7339 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551 1
Q7404 21785000550AS T.R,PNP,DUAL,HN4A06J,SOT-25,TOSHIBA CVTHN4A06J 1
Q7414 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q7418 00D2710314903 T.R HVTKTA1024YT 1
Q7420,7421 00D2730471907 T.R HVTKTC3206YAT 2
Q7425 963219003340S T.R,BIAS CVTKTC3964 1
Q7431 00D9630235301 T.R,POWER(Pc130W) HVT2SD2560 1
Q7432 00D9630235204 T.R,POWER(Pc130W) HVT2SB1647 1
Q7438 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q7439 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551 1
Q7504 21785000550AS T.R,PNP,DUAL,HN4A06J,SOT-25,TOSHIBA CVTHN4A06J 1
Q7514 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q7518 00D2710314903 T.R HVTKTA1024YT 1
Q7520,7521 00D2730471907 T.R HVTKTC3206YAT 2
Q7525 963219003340S T.R,BIAS CVTKTC3964 1
Q7531 00D9630235301 T.R,POWER(Pc130W) HVT2SD2560 1
Q7532 00D9630235204 T.R,POWER(Pc130W) HVT2SB1647 1
Q7538 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q7539 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551 1
Q7604 21785000550AS T.R,PNP,DUAL,HN4A06J,SOT-25,TOSHIBA CVTHN4A06J 1
Q7614 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q7618 00D2710314903 T.R HVTKTA1024YT 1
Q7620,7621 00D2730471907 T.R HVTKTC3206YAT 2
Q7625 963219003340S T.R,BIAS CVTKTC3964 1
Q7631 00D9630235301 T.R,POWER(Pc130W) HVT2SD2560 1
Q7632 00D9630235204 T.R,POWER(Pc130W) HVT2SB1647 1
Q7638 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q7639 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551 1
Q7704 21785000550AS T.R,PNP,DUAL,HN4A06J,SOT-25,TOSHIBA CVTHN4A06J 1
Q7714 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q7718 00D2710314903 T.R HVTKTA1024YT 1
Q7720,7721 00D2730471907 T.R HVTKTC3206YAT 2
Q7725 963219003340S T.R,BIAS CVTKTC3964 1
Q7731 00D9630235301 T.R,POWER(Pc130W) HVT2SD2560 1
Q7732 00D9630235204 T.R,POWER(Pc130W) HVT2SB1647 1
Q7738 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q7739 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551 1
ZD714 943202010080S DIODE,ZENER,1/2W,5.1V CVDZJ5.1BT 1
ZD724 943202010080S DIODE,ZENER,1/2W,5.1V CVDZJ5.1BT 1
ZD734 943202010080S DIODE,ZENER,1/2W,5.1V CVDZJ5.1BT 1
ZD744 943202010080S DIODE,ZENER,1/2W,5.1V CVDZJ5.1BT 1
ZD754 943202010080S DIODE,ZENER,1/2W,5.1V CVDZJ5.1BT 1
ZD764 943202010080S DIODE,ZENER,1/2W,5.1V CVDZJ5.1BT 1
ZD774 943202010080S DIODE,ZENER,1/2W,5.1V CVDZJ5.1BT 1
RESISTOR GROUP
R7001 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R7002 nsp RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
! R7012 943252101000S PTCTHEMISTORS,CHIP
(
65'C
)
CRTPRF18BG471Q
B
1*
! R7014 252310006506S PTCTHEMISTORS,CHIP
(
115'C
)
CRTPRF18BB471Q
B
1
R7016 nsp RES,CARBON(1/5W,3.3Kohm,J) CRD20TJ332T 1
