Denon AVR-X4100W

INPUT
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
C4729,4730 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T 2
C4742 00D2544583971 CAP,ELEC(ELNAROBSERIES,47uF/50V) CCEA1HROB470T 1
C4761-4763 00D2544583971 CAP,ELEC(ELNAROBSERIES,47uF/50V) CCEA1HROB470T 3
C4764-4771 00D9430175001 CAP,ELECT(25V/47uF) CCEA1EH470T 8
C4773,4774 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 2
C4781-4784 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 4
C4801,4802 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 2
C4803-4806 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG CCUS1H103KCS 4
C4811,4812 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 2
C4819,4820 nsp CAP,CHIP(1608,50V/68pF,C0G)_SAMSUNG CCUS1H680JAS 2
C4823,4824 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG CCUS1H101JAS 2
C4825-4828 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 4
C4831,4832 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 2
C4851,4852 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 2
C4853-4856 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG CCUS1H103KCS 4
C4861,4862 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 2
C4869,4870 nsp CAP,CHIP(1608,50V/68pF,C0G)_SAMSUNG CCUS1H680JAS 2
C4873,4874 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG CCUS1H101JAS 2
C4875-4878 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 4
C4881,4882 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 2
C4891,4892 00D9430148708 CAP,ELECT(50V/47uF) CCEA1HH470T 2
C4901 nsp CAP,ELECT(16V/100uF) CCEA1CH101T 1
C4903 nsp CAP,ELECT(16V/100uF) CCEA1CH101T 1
C4905 nsp CAP,ELECT(16V/100uF) CCEA1CH101T 1
C4907 nsp CAP,ELECT(16V/100uF) CCEA1CH101T 1
C4909-4911 nsp CAP,ELECT(16V/100uF) CCEA1CH101T 3
C4913 nsp CAP,ELECT(16V/100uF) CCEA1CH101T 1
C4921 nsp CAP,CHIP(1608,16V/0.15uF,X7R,X7S)_SAMSUNG CCUS1C154KCS 1
C4922 nsp CAP,CHIP(1608,50V/0.047uF,X7R)_SAMSUNG CCUS1H473KCS 1
C4923 nsp CAP,CHIP(1608,50V/0.022uF,X7R)_SAMSUNG CCUS1H223KCS 1
C4924 nsp CAP,CHIP(1608,16V/0.15uF,X7R,X7S)_SAMSUNG CCUS1C154KCS 1
C4925 nsp CAP,CHIP(1608,50V/0.047uF,X7R)_SAMSUNG CCUS1H473KCS 1
C4926 nsp CAP,CHIP(1608,50V/0.022uF,X7R)_SAMSUNG CCUS1H223KCS 1
C4935,4936 00D9430103905 CAP,ELECT(16V/470uF) CCEA1CH471T 2
C6802 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C6803 nsp CAP,ELECT(10V/220uF)-S CCEA1AKS221T 1
C8703,8704 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 2
C8707,8708 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 2
C8709,8710 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG CCUS1H331JAS 2
C8719 nsp CAP,ELECT(50V/0.1uF) CCEA1HH0R1T 1
C8723,8724 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 2
C8727,8728 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 2
C8729,8730 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG CCUS1H331JAS 2
C8739 nsp CAP,ELECT(50V/0.1uF) CCEA1HH0R1T 1
C8740 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG CCUS1H103KCS 1
C8743,8744 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 2
C8747,8748 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 2
C8749,8750 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG CCUS1H331JAS 2
C8759 nsp CAP,ELECT(50V/0.1uF) CCEA1HH0R1T 1
C8767,8768 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 2
C8769,8770 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG CCUS1H331JAS 2
C8780 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG CCUS1H103KCS 1
C8787,8788 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 2
C8789,8790 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG CCUS1H331JAS 2
C8800 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG CCUS1H103KCS 1
C8803 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 1
C8807 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 1
C8809 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG CCUS1H331JAS 1
C8819 nsp CAP,ELECT(50V/0.1uF) CCEA1HH0R1T 1
C8820 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG CCUS1H103KCS 1
C8849 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C8860 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG CCUS1H103KCS 1
C8869 nsp CAP,ELECT(50V/0.1uF) CCEA1HH0R1T 1
C8913,8914 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 2
C8917,8918 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 2
C8919,8920 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG CCUS1H331JAS 2
C8929 nsp CAP,ELECT(50V/0.47uF) CCEA1HHR47T 1
C8963,8964 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 2
C8967,8968 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 2
C8969,8970 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG CCUS1H331JAS 2
C8979 nsp CAP,ELECT(50V/0.47uF) CCEA1HHR47T 1
C8980 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG CCUS1H103KCS 1
C8991,8992 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 2
OTHER PARTS GROUP
BK469 nsp EARTH,INPUT CMC1A440 1
BK608 nsp EARTH,USB CMC1A432 1
BN23C nsp PINSOCKET(21P,1.25mm,ANGLE,B-TO-B) CJP21HJ282Z 1
BN24C nsp PINSOCKET(27P,1.25mm,ANGLE,B-TO-B) CJP27HJ282Z 1
BN26C nsp PINSOCKET(15P,1.25mm,ANGLE,B-TO-B) CJP15HJ282Z 1
BN321
EXPLODED
_
C10
nsp WIREASS'Y(5P,2.0MM,500MM,UL2725#24/#28,1P+2C)USB CWB8A005500HC 1 *
BN461
EXPLODED
_
C25
nsp WIREASS'YLocking(YH)(13P,2MM,180MM,#26) CWB1B013180HC 1 *
BN64C nsp PINSOCKET(13P,1.25mm,ANGLE,B-TO-B) CJP13HJ282Z 1
CN706 nsp LOCK-WAFER/STRAIGHT/2MMPITCH/3PIN CJP03GI288ZY 1
JK461-463 943643101570S JACK,4P(W/R,W/R),SEPA-GND CJJ4P048U 3
JK608 943643102460D JACK,USBANGLETYPE(BLACK1.5A) CJJ9X014Z 1
JK871 643010079004S JACK,4P(W/R,W/B),SEPA-GND,SILVER CJJ4P077Z 1
JK875 943643101570S JACK,4P(W/R,W/R),SEPA-GND CJJ4P048U 1
JK879 943643101570S JACK,4P(W/R,W/R),SEPA-GND CJJ4P048U 1
JK881 943643010160S JACK,1P(BK),SEPA-GND,SILVER CJJ4M046U 1
JK886 943643010150S JACK,2P(W/R),SEPA-GND,SILVER CJJ4N034U 1
JK891 943643101570S JACK,4P(W/R,W/R),SEPA-GND CJJ4P048U 1
L4661,4662 00D9430193601 COIL,TOROIDAL E2 CLU9S004Z 2
L6831 nsp FERRITECHIPBEAD(2012/220R) CLZBLM21PG221S
N
1
RY875 943682000810S RELAY,BC3-12H,DC12V,2C2P CSL4A016ZU 1
RY877-881 943682000810S RELAY,BC3-12H,DC12V,2C2P CSL4A016ZU 5
12
