Denon AVR-X4100W

F_HDMI
F
_
HDMI PCB ASS'
Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
IC541 963236101380P I.C,HDMIBUFFER CVIAD8195ACPZ 1
Q5401 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C 1
Q5402 943216500040S T.R,RT1N241C(22K-22K) CVTRT1N241C 1
RESISTOR GROUP
R5401 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R5403 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R5404 nsp RES,CHIP(1005/5%/22Kohm) CRJ06IJ223T 1
R5405 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R5407 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R5409 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T 1
R5410,5411 nsp RES,CHIP(1005/5%/2Kohm) CRJ06IJ202T 2
RN501-504 nsp RES,CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 4
CAPACIITORS GROUP
C5401-5405 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 5
C5406 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C5407-5411 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 5
C5412 nsp CAP,CHIP(1005,25V/0.01uF,X7R)_SAMSUNG CCUI1E103KCS 1
C5413 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C5414 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C5420-5423 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 4
C5424 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
OTHER PARTS GROUP
BK541 nsp EARTH,HDMI CMC2A432 1
CN541 nsp WAFER,FFC,SMD(23P-1mm,STRAIGHT) CJP23GA193ZY 1
JK541 943643103000S JACK,HDMI(TYPE-A,SMT-19P,W/OFLANGE) CJJ9H022Z 1 *
L5401,5402 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
