Denon AVR-X4100W

SMPS
SMPS PCB ASS'
Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D9001-9006 00D9630328409 DIODE,RECTIFIER,AXIAL CVD1N4007ST 6
D9008,9009 00D9630328409 DIODE,RECTIFIER,AXIAL CVD1N4007ST 2
D9010 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D9012
EXPLODED
_
M17
nsp HEATSINKASS'Y(CVDSRL3060P+CMY3A238) CVDSRL3060PBYA 1
D9013 00D9630328409 DIODE,RECTIFIER,AXIAL CVD1N4007ST 1
IC901
EXPLODED
_
M16
nsp HEATSINKASS'Y(CVITOP256YN+CMY6A025) CVITOP256YNBZA 1
! IC902 963239010480S I.C,PHOTOCOUPLE
R
CVIPC123Y22FZ0
F
1
IC903 212050010508S I.C,SHUNTREGULATOR(TO-92) CVIKIA2431AP 1
Q9001 943229500110S F.E.T,INK0010AC1(N-CH,SC-59,MOSFET,ISAHAYA) CVTINK0010AC1 1
Q9003 943214500020S T.R,2SC3052 CVT2SC3052 1
ZD908 943202500850S TVSDIODE,120V/5W E3/JP CVDP6KE120AT 1
ZD911 943202500860S TVSDIODE,150V/5W CVDP6KE150AT 1
ZD918 963202010440S DIODE,ZENER,1/2W,22V CVDZJ22BT 1
ZD919 00D9600095607 DIODE,ZENER,1/2W,5.6V CVDZJ5.6BT 1
ZD920 00D2760762958 DIODE,ZENER,1/2W,39V CVDZJ39BT 1
ZD921 00D9430196306 DIODE,ZENER,1/2W,7.5V E3 CVDZJ7.5BT 1
ZD921 943202000940S DIODE,ZENER,1/2W,16V E2 CVDZJ16BT 1
ZD921 00D9600095607 DIODE,ZENER,1/2W,5.6V JP CVDZJ5.6BT 1
ZD922 00D2760762958 DIODE,ZENER,1/2W,39V CVDZJ39BT 1
RESISTOR GROUP
R9004 nsp RES,CARBON(1/5W,330Kohm,J) CRD20TJ334T 1
R9006 nsp RES,CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R9008,9009 nsp RES,CARBON(1/5W,2.2Mohm,J) E3/JP CRD20TJ225T 2
R9010 nsp RES,CARBON(1/5W,1Mohm,J) E3/JP CRD20TJ105T 1
R9014 nsp RES,CHIP(1608/5%/270Kohm) E3/JP CRJ10DJ274T 1
R9014 nsp RES,CHIP(1608/5%/56Kohm) E2 CRJ10DJ563T 1
R9015 nsp RES,CHIP(1608/5%/8.2Kohm) CRJ10DJ822T 1
R9016 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R9017 nsp RES,CARBON(1/5W,6.8ohm,J) CRD20TJ6R8T 1
R9018 nsp RES,CARBON(1/5W,56ohm,J) CRD20TJ560T 1
R9019 nsp RES,CARBON(1/5W,3.3Kohm,J) CRD20TJ332T 1
R9020 nsp RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R9021 nsp RES,CHIP(1608/1%/22Kohm) CRJ10DF2202T 1
R9024 nsp RES,CHIP(1608/1%/6.8Kohm) CRJ10DF6801T 1
R9026 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R9027 nsp RES,CARBON(1/5W,4.7Kohm,J) CRD20TJ472T 1
! R9031 943121501000S RES,SURGE,
(
8.2MOHM,5%,1/2W,PRCTYPE
)
CRO50TJ825
T
1
R9035-9037 nsp RES,CHIP(2012/5%/1Mohm) CRJ18AJ105T 3
CAPACIITORS GROUP
! C9001-9003 963132011940S CAP,CERAMIC
(
X1/Y2,0.01uF,AC250V
)
CCKDKY103MFM 3
C9004
EXPLODED
_
C21
943134503040S CAP,ELECT(200V/220uF),105'C E3/JP CCET200NHA221E
S
1
C9004 963134010200S CAP,ELECT(400V/100UF,18X40,NHA) E2 CCET400NHA101E
S
1
C9006 nsp CAP,CHIP(1608,50V/0.047uF,X7R)_SAMSUNG CCUS1H473KCS 1
C9007 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG CCUS1H103KCS 1
C9008 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C9009 00D9430175108 CAP,ELECT(50V/10uF),105'C CCEA1HNXA100TS 1
C9010 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C9012 963132010120S CAP,CERAMIC(DC1KV/1000pF) CCKDDEH102KCM 1
C9016 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C9017 00MOA47602520 CAP,ELECT(25V/47uF),105'C CCEA1ENXA470TS 1
C9018 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C9019 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 1
C9020-9022
EXPLODED_C16
EXPLODED_C17
EXPLODED C18
963134010220S CAP,ELECT(6.3V/5600uF) CCEA0JNXA562ES 3
C9024 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
! C9028 963132011930S CAP,CERAMIC
(
X1/Y1,2200P,AC250V
)
CCKDKX222MEM 1
C9029 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
OTHER PARTS GROUP
BK901,902 nsp BRACKET,PCBM3 CMD1A834 2
BK903 nsp BRACKET,PCB CMD1A629 1
BN903
EXPLODED
_
C19
nsp WIREASS'YLOCKING(5P,2.5MM,400MM,UL1569#22,105) CWB7D0054003D 1
CN901 nsp WAFER,2P,3.96mm CJP02KA060ZY 1
CN902 nsp WAFER,2P,7.92mm CJP02GA89ZY 1
! CX901,902 943139500020S CAP,POLYPROPYLENEFILM
(
0.1uF/275VAC
)
CCQF2E104KZE-T 2
! CY901,902 963134011730S CAP,CERAMIC
(
X1/Y1,470P,AC250V
)
CCKDKX471KBM 2
! F9001 963652010510S FUSE
(
S506Series,250V,2A
)
E3/JP CBA2C2000TLE
C
1
! F9001 963652010500S FUSE
(
S506Series,250V,1.6A
)
E2 CBA2C1600TLE
C
1
F9001,9002 nsp HOLDER,FUSE KJCFC5S 2
! F9002 90M-FS001220
R
FUSE
(
218Series,250V/8A
)
E3/JP KBA2C8000TLE
Y
1
! F9002 90M-FS001490
R
FUSE
(
218Series,250V/4A
)
E2 KBA2C4000TLE
Y
1
!
LF901
EXPLODED
_
C22
943121501000S LINEFILTER(1.2A,29mH) E3/JP CLZ9Z176Z 1
! LF901 943134503040S LINEFILTER
(
0.7A,65mH
)
E2 CLZ9Z177Z 1
! RY901 963682010370S RELAY,HL31-1AT-5H,DC5V,1C1
P
CSL1C006ZE 1
!
T9001
EXPLODED
_
C20
943102100350S TRANS,SWITCHING CLT9Z093ZE 1
EXPLODED_M18 nsp SHEILD,TRANSCOVER CMC1A445 1
★ nsp RUBBER,TRANS CHG1A587 1
★ nsp TAPE,BOTHSIDE C4FA101 0.02
★ nsp TRHEATSINK CMY3A238 1
★ nsp SCREW CTW3+10JR 1
★ 943209500030S DIODE,LOWFORWARDSCHOTTKYRECTIFIER CVDSRL3060P 1
★ nsp HEATSINK,TR CMY6A025 1
★ nsp SCREW CTB3+8JR 1
! ★ 23901007520AS I.C,OFFLINEPOWERSWITCH CVITOP256YN 1
