Denon AVR-X4100W

FRONTCNT
FRONTCNT PCB ASS'
Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
IC301 943239101080S I.C,DAC(8CH,HTSSOP-48) CVIPCM1690DCAR 1
IC302-305 943232100380S I.C,DUALOPAMP(SOP-8P) CVINJM8080G 4
IC311 943239101080S I.C,DAC(8CH,HTSSOP-48) CVIPCM1690DCAR 1
IC312,313 943232100380S I.C,DUALOPAMP(SOP-8P) CVINJM8080G 2
RESISTOR GROUP
R3001 nsp RES,CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R3002 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R3003,3004 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R3011-3014 nsp RES,CHIP(1608/5%/15Kohm) CRJ10DJ153T 4
R3015-3018 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 4
R3019-3022 nsp RES,CHIP(1608/5%/12Kohm) CRJ10DJ123T 4
R3023-3026 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 4
R3027,3028 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R3029-3032 nsp RES,CHIP(1608/5%/15Kohm) CRJ10DJ153T 4
R3033 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R3035 nsp RES,CHIP(1608/5%/12Kohm) CRJ10DJ123T 1
R3036 nsp RES,CHIP(1608/5%/22Kohm) CRJ10DJ223T 1
R3037 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R3038 nsp RES,CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R3039 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R3040 nsp RES,CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R3041 nsp RES,CHIP(1608/5%/12Kohm) CRJ10DJ123T 1
R3042 nsp RES,CHIP(1608/5%/22Kohm) CRJ10DJ223T 1
R3043 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R3045,3046 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R3047 nsp RES,CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R3049 nsp RES,CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R3053 nsp RES,CHIP(1608/5%/22Kohm) CRJ10DJ223T 1
R3055 nsp RES,CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R3057 nsp RES,CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R3059 nsp RES,CHIP(1608/5%/22Kohm) CRJ10DJ223T 1
R3063 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R3065-3068 nsp RES,CHIP(1608/5%/15Kohm) CRJ10DJ153T 4
R3069 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R3071 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R3073,3074 nsp RES,CHIP(1608/5%/12Kohm) CRJ10DJ123T 2
R3075-3078 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 4
R3079,3080 nsp RES,CHIP(1608/5%/12Kohm) CRJ10DJ123T 2
R3081 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R3083 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R3085,3086 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R3101 nsp RES,CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R3102 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R3103,3104 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R3111-3114 nsp RES,CHIP(1608/5%/15Kohm) CRJ10DJ153T 4
R3115,3116 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 2
R3117,3118 nsp RES,CHIP(1608/5%/12Kohm) CRJ10DJ123T 2
R3119-3122 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 4
R3123,3124 nsp RES,CHIP(1608/5%/12Kohm) CRJ10DJ123T 2
R3125,3126 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 2
R3127,3128 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R3129-3132 nsp RES,CHIP(1608/5%/15Kohm) CRJ10DJ153T 4
R3133,3134 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 2
R3135,3136 nsp RES,CHIP(1608/5%/12Kohm) CRJ10DJ123T 2
R3137-3140 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 4
R3141,3142 nsp RES,CHIP(1608/5%/12Kohm) CRJ10DJ123T 2
R3143,3144 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 2
R3145 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R3147 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
CAPACIITORS GROUP
C3001 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C3002 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C3003 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C3004 00D2544577958 CAP,ELECT(16V/220uF),ELNA/RA3 CCEA1CRA3221T 1
C3005 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C3006 00D9430148708 CAP,ELECT(50V/47uF) CCEA1HH470T 1
C3007 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C3012,3013 nsp CAP,CHIP(2012,50V/1800pF,MURATAGRM21) CCUMUC1H182JAM 2
C3015-3018 nsp CAP,CHIP(2012,50V/270pF,MURATAGRM21) CCUMUC1H271JAM 4
C3021,3022 nsp CAP,ELECT(10V/220uF) CCEA1AH221T 2
C3023 nsp CAP,CHIP(2012,50V/1800pF,MURATAGRM21) CCUMUC1H182JAM 1
C3024 nsp CAP,CHIP(2012,50V/1000pF,MURATAGRM21) CCUMUC1H102JAM 1
C3025 nsp CAP,CHIP(2012,50V/270pF,MURATAGRM21) CCUMUC1H271JAM 1
C3026 nsp CAP,CHIP(2012,50V/150pF,MURATAGRM21) CCUMUC1H151JAM 1 *
C3027 nsp CAP,CHIP(2012,50V/270pF,MURATAGRM21) CCUMUC1H271JAM 1
C3028 nsp CAP,CHIP(2012,50V/150pF,MURATAGRM21) CCUMUC1H151JAM 1 *
C3031 nsp CAP,CHIP(2012,50V/1000pF,MURATAGRM21) CCUMUC1H102JAM 1
C3032,3033 nsp CAP,CHIP(2012,50V/150pF,MURATAGRM21) CCUMUC1H151JAM 2 *
C3037,3038 nsp CAP,CHIP(2012,50V/1800pF,MURATAGRM21) CCUMUC1H182JAM 2
C3039-3042 nsp CAP,CHIP(2012,50V/270pF,MURATAGRM21) CCUMUC1H271JAM 4
C3055,3056 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 2
C3057,3058 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG CCUS1H102KCS 2
C3061-3063 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG CCUS1H102KCS 3
C3064-3066 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 3
C3067-3069 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG CCUS1H102KCS 3
C3072-3074 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 3
C3101 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C3102 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C3103 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C3104 00D9430148708 CAP,ELECT(50V/47uF) CCEA1HH470T 1
C3105 00D2544577958 CAP,ELECT(16V/220uF),ELNA/RA3 CCEA1CRA3221T 1
C3106,3107 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 2
C3121,3122 nsp CAP,CHIP(2012,50V/1800pF,MURATAGRM21) CCUMUC1H182JAM 2
C3123-3126 nsp CAP,CHIP(2012,50V/270pF,MURATAGRM21) CCUMUC1H271JAM 4
C3129,3130 nsp CAP,ELECT(10V/220uF) CCEA1AH221T 2
C3131,3132 nsp CAP,CHIP(2012,50V/1800pF,MURATAGRM21) CCUMUC1H182JAM 2
C3133-3136 nsp CAP,CHIP(2012,50V/270pF,MURATAGRM21) CCUMUC1H271JAM 4
C3147,3148 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 2
