Denon AVR-X4100W

Paths conrmation item Display Settings Contents of conrmation Remarks
6
Analog A/D
MAIN ZONE:
A 0 6 : A D
Input Source : CBL/SAT
Input Mode : Analog xed
Sound mode : Multi Ch Stereo
Z2 Vol : 60(-20dB)
Amp assign : 7.1ch
Speaker Select : Floor
Speaker Cong : All Speaker=Small/Subwoofer=2spkrs
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Front L/R, Center, Surround L/R, Surround Back L/R)
・ Analog input ⇒ Preout output, SW(20Hz) (Front L/R, Center, Surround L/R, Surround Back L/R, Subwoofer)
(
b
The input source can be switched to any source except CBL/SAT.）
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
7
Analog Amp Assign
(Amp Assign：ZONE2)
A 0 7 : A S S I G N - Z 2
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Stereo
Amp assign : 5.1ch + ZONE2
Speaker for ZONE2 : Surround Back
MAIN ZONE : ON
ZONE2 : ON
Z2 Source : Source
Z2 Vol : 60(-20dB)
ZONE3 : OFF
・Analog input ⇒ Speaker output(Surround Back L/R → ZONE2 L/R)
・Analog input ⇒ Preout output (ZONE2 L/R)
(
b
The input source can be switched to any source except CBL/SAT.）
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
8
Analog Amp Assign
(Amp Assign：ZONE3)
A 0 8 : A S S I G N - Z 3
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Stereo
Amp assign : 5.1ch + ZONE3
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : ON
ZONE3 Source : Source
Z3 Vol. : 60.0(-20.0dB）
・Analog input ⇒ Speaker output (Surround Back L/R → ZONE3 L/R)
・Analoginput ⇒ Preout output (ZONE3 L/R)
(
b
The input source can be switched to any source except CBL/SAT.）
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
9
Analog Amp Assign
(Amp Assign：ZONE2/ZONE3-MONO）
A 0 9 : A S S I G N - Z 3 / 3 M
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
Amp assign : 5.1ch + ZONE2/3-MONO
MAIN ZONE : ON
ZONE2 : ON
Z2 Source : Source
Z2 Vol : 60(-20dB）
ZONE3 : ON
Z3 Source : Source
Z3 Vol : 60(-20dB）
・Analog input ⇒ Speaker output (Surround Back L → ZONE2 MONO, Surround Back R → ZONE3 MONO)
・Analog input ⇒ Preout output (ZONE2 L/R → ZONE2 MONO, ZONE3 L/R → ZONE3 MONO)
(
b
The input source can be switched to any source except CBL/SAT.）
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
10
Amp Assign
(Bi-Amp)
A 1 1 : A S S I G N - B i A M P
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Multi Ch Stereo
Amp assign : 5.1ch (Bi-Amp)
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Surround Back L/R → Front L/R）
(
b
The input source can be switched to any source except CBL/SAT.）
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
11
Front Height
A 1 4 : F R O N T H E I G H T
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Multi Ch Stereo
Vol. : 60.0(-20.0dB）
Amp assign : 9.1ch
Height Speakers : 2Height Speakers
Height Layout : Front Height
Pre-out Channel : Front
Speaker Cong : Surround Back=None
Speaker Select(Audio_Surround Parameter) : Floor & Height
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Height 1 L/R → Top Front L/R）
・Analog input ⇒ Preout output (Height 1 L/R → Front Height)
(
b
The input source can be switched to any source except CBL/SAT.）
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
12
Front Wide
A 1 5 : F R O N T W I D E
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Multi Ch Stereo
Vol. : 60.0(-20.0dB）
Amp assign : 7.1ch
Speaker Cong : S.Back=None
Speaker Select(Audio_Surround Parameter) : Front
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Front Wide L/R）
・Analog input ⇒ Preout output (Front Wide L/R）
(
b
The input source can be switched to any source except CBL/SAT.）
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
g.06a
g.06b
g.07
g.08
g.09
g.10
g.11a
g.11b
g.12a
g.12b
28
