Paths conrmation item Display Settings Contents of conrmation Remarks
13
Front Amp>>Front Wide
A 2 1 : F - A M P W I D E
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Multi ch Stereo
Vol. : 60.0(-20.0dB）
Amp assign : 9.1ch
Height Speakers : 2Height Speakers
Height Layout : Front Height
Pre-out Channel : Front
Speaker Conog :Front Height=None
Speaker Select(Audio_Surround Parameter)=Floor
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Front Wide L/R)
・Analog input ⇒ Preout output (Front Wide L/R)
(
b
The input source can be switched to any source except CBL/SAT.）
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
14
Front Amp>>Surround Back
A 2 2 : F - A M P B A C K
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Multi ch Stereo
Vol. : 60.0(-20.0dB）
Amp assign : 9.1ch
Height Speakers : 2Height Speakers
Height Layout : Front Height
Pre-out Channel : Front
Speaker Conog : Front Wide=None
Speaker Select(Audio_Surround Parameter)=Floor & Height
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Surround Back L/R)
・Analog input ⇒ Preout output (Surround Back L/R)
(
b
The input source can be switched to any source except CBL/SAT.）
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
15
Height Amp
A 2 4 : H E I G H T
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Multi ch Stereo
Vol. : 60.0(-20.0dB）
Amp assign : 9.1ch
Height Speakers=4Height Speakers
Height Layout=Top Front & Top Rear
Pre-out Channel=Top Rear
Speaker Conog : Surround Back=None
Speaker Select(Audio_Surround Parameter)=Floor & Height
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Height1 L/R → Top Front)
・Analog input ⇒ Preout output (Height1 L/R → Top Front, Height2 → Top Rear L/R）
(
b
The input source can be switched to any source except CBL/SAT.）
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
g.13a
g.13b
g.14a
g.14b
g.15a
g.15b
