3. I/O PCB ASS'Y
(1) Disconnecttheconnectorwire.
(2) Removethescrewsandthenuts.
SIDE PANEL
TOP PANEL
→
I/O PCB ASS’ Y
→
Proceeding :
cut
CN82
FFC cable
Outside of CD macha foot
CN600
MIC EQ PCB ASS’Y
I/O PCB ASS’Y
cut
CN82
FFC cable
Outside of CD macha foot
※Don’t lose CUSHION.
NUT
Direction of photograph: D
Direction of photograph: B
