Denon DN-MC6000 - Control PCB Assy

15
6. CONTROL PCB ASS'Y
(1) Disconnecttheconnectorwire.
(2) Removethesolder.
SIDE PANEL
TOP PANEL
→
CHASSIS ASS’ Y
→
→
CONTROL SUB ASSY
Proceeding :
cut
CN82
FFC cable
Outside of CD macha foot
CN105 CN103 CN104
cut
CN82
FFC cable
Outside of CD macha foot
SOLDER
SOLDER
