67
PARTS LIST OF P.W.B. UNIT
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
CONTROL P.C.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC100 941243004430P
MIDI IC ASS'Y
IC(MC9S08AW60CPUE,LQFP-64)
704-6000-9601 *
IC101 941239003270S
IC(BA05FP-E2,TO-252)
417-U101-497
IC102 941248004780P
DSP IC ASS'Y
IC(24LC128T-I/SN,SOIC-8)
704-6000-9602 *
IC103-105 00D9587058709
IC(74AHC595DR,SOP-16)
417-HDJ9800-643
IC106 941239004450P
IC(BD5238G,SO-14)
417-MC6000-1021 *
IC115-119 941239004980P
IC(74HC4052D/74HC4052DT,SMD)
417-QSPAND-432
IC120,121 941243004220P
IC(PIC16F616-I/SL,SOIC-16)
417-RMP3-936
IC122 941239004980P
IC(74HC4052D/74HC4052DT,SMD)
417-QSPAND-432
IC123 941239004460P
IC(74HC165D,SO-16)
417-CDG9000-707 *
IC124 941239004470P
IC(74HCT08DT,SO-14)
417-MC6000-1017 *
D103,104 941263002620S
CHIP LED(JA-3020YG,3*2,YELLOW/GREEN)
410-MIX101-374
D105,106 941263002610S
CHIP LED(YELLOW,JA-3020Y,3*2)
410-F300-377
D107,108 941263002620S
CHIP LED(JA-3020YG,3*2,YELLOW/GREEN)
410-MIX101-374
D109 941263002610S
CHIP LED(YELLOW,JA-3020Y,3*2)
410-F300-377
D110,111 941263003110S
CHIP LED(JA-3020R,3*2,RED)
410-MIX101-373
D112-115 941263002610S
CHIP LED(YELLOW,JA-3020Y,3*2)
410-F300-377
D116 941263004500P
LED ( GREEN )
410-CD6000-124 *
D117-122 941263002610S
CHIP LED(YELLOW,JA-3020Y,3*2)
410-F300-377
D123,124 941263004510P
LED ( L-7104QBD/TB/TD-D,BLUE )
410-MU12B1-389 *
D125,126 941263002010S
CHIP LED(JA-3020B,3*2,BLUE)
410-S700-375
D127,128 941263002620S
CHIP LED(JA-3020YG,3*2,YELLOW/GREEN)
410-MIX101-374
D129,130 941263003110S
CHIP LED(JA-3020R,3*2,RED)
410-MIX101-373
D131 00D9587051706
LED (LTL-16KE,RED )
410-CD6000-122
D132,133 941263004510P
LED ( L-7104QBD/TB/TD-D,BLUE )
410-MU12B1-389 *
D134 00D9587051706
LED (LTL-16KE,RED )
410-CD6000-122
D135-139 941263004500P
LED ( GREEN )
410-CD6000-124 *
D140-143 941263004480P
LED ( LTL-16KA )
410-HDJ2650-163 *
D144 00D9587051706
LED (LTL-16KE,RED )
410-CD6000-122
D145-D149 941263004500P
LED ( GREEN )
410-CD6000-124 *
D150-D153 941263004480P
LED ( LTL-16KA )
410-HDJ2650-163 *
D154 00D9587051706
LED (LTL-16KE,RED )
410-CD6000-122
D155-158 941263002620S
CHIP LED(JA-3020YG,3*2,YELLOW/GREEN)
410-MIX101-374
D159 941263002010S
CHIP LED(JA-3020B,3*2,BLUE)
410-S700-375
D160 941263003110S
CHIP LED(JA-3020R,3*2,RED)
410-MIX101-373
D161 941263002010S
CHIP LED(JA-3020B,3*2,BLUE)
410-S700-375
D162 941263003110S
CHIP LED(JA-3020R,3*2,RED)
410-MIX101-373
D163-165 941263002610S
CHIP LED(YELLOW,JA-3020Y,3*2)
410-F300-377
D166,167 941263002620S
CHIP LED(JA-3020YG,3*2,YELLOW/GREEN)
410-MIX101-374
D168,169 941263002610S
CHIP LED(YELLOW,JA-3020Y,3*2)
410-F300-377
D170,171 941263002620S
CHIP LED(JA-3020YG,3*2,YELLOW/GREEN)
410-MIX101-374
D172 941263002610S
CHIP LED(YELLOW,JA-3020Y,3*2)
410-F300-377
D173,174 941263003110S
CHIP LED(JA-3020R,3*2,RED)
410-MIX101-373
D175,176 941263002610S
CHIP LED(YELLOW,JA-3020Y,3*2)
410-F300-377
D177 941263002620S
CHIP LED(JA-3020YG,3*2,YELLOW/GREEN)
410-MIX101-374
D178,179 941263002610S
CHIP LED(YELLOW,JA-3020Y,3*2)
410-F300-377
D180 941263002620S
CHIP LED(JA-3020YG,3*2,YELLOW/GREEN)
410-MIX101-374
D181,182 941263002610S
CHIP LED(YELLOW,JA-3020Y,3*2)
410-F300-377
D183 941263002620S
CHIP LED(JA-3020YG,3*2,YELLOW/GREEN)
410-MIX101-374
D184,185 941263002610S
CHIP LED(YELLOW,JA-3020Y,3*2)
410-F300-377
D186 941263002620S
CHIP LED(JA-3020YG,3*2,YELLOW/GREEN)
410-MIX101-374
D187-190 941263002610S
CHIP LED(YELLOW,JA-3020Y,3*2)
410-F300-377
D191-196 941263002620S
CHIP LED(JA-3020YG,3*2,YELLOW/GREEN)
410-MIX101-374
D197,198 941263002610S
CHIP LED(YELLOW,JA-3020Y,3*2)
410-F300-377
D199 941263004500P
LED ( GREEN )
410-CD6000-124 *
NOTE :
When update Firmware, please
conrm a last version in SDI.
Use the service board after
updating it.
To Next Page
