Denon DN-MC6000 - MIC EQ PCB Assy

12
4. MIC EQ PCB ASS'Y
(1) Disconnecttheconnectorwire.
(2) Removethescrews,thenutsandtheknobs.
NOTE
：
 Turntotightenascrews
①
→
②
.
SIDE PANEL
TOP PANEL
→
MIC EQ PCB ASS’ Y
→
Proceeding :
cut
CN82
FFC cable
Outside of CD macha foot
CN600
CN1000
MIC EQ PCB ASS’Y
I/O PCB ASS’Y
MIC EQ PCB ASS’Y
I/O PCB ASS’Y
cut
CN82
FFC cable
Outside of CD macha foot
q
q
w
w
NUT KNOB
Direction of photograph: A
※Don’t lose CUSHION.
