Denon DN-MC6000 - MIC EQ P.C.B. Unit Assy

80
Mic EQ P.C.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC1000,1001 941239004980P IC(74HC4052D/74HC4052DT,SMD) 417-QSPAND-432 *
Q1000 00D9587057807 TRANSISTOR(TR DTA124TSATP) 416-KE200S-024
D1001 nsp SWITCHING DIODE( ISS133 T-77) 414-3113-005
RESISTOR GROUP
R1000 nsp CARBON FILM RESISTOR((47K OHM,1/6W,J,T-26) 412-3113-063
R1001 nsp CARBON FILM RESISTOR(470 OHM,1/6W,J,T-26) 412-3113-056
R1002-1009 nsp CARBON FILM RESISTOR(1K OHM,1/6W,J,T-26) 412-3113-078
R1010-1022 nsp CARBON FILM RESISTOR((3.3K OHM,1/6W,J,T-26) 412-3113-057
R1023,1024 nsp CHIP RESISTOR(0 OHM,1/10W3,J,TP,50V) 412-CDVD2001-552
R1025 nsp CARBON FILM RESISTOR((47K OHM,1/6W,J,T-26) 412-3113-063
CAPACITORS GROUP
C1000-1012 nsp CERAMIC CAPACITOR(0.01uF/50V,Z,TAPING,Z5V) 413-3113-028
C1013,1014 nsp CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035
C1015,1016 nsp CERAMIC CAPACITOR(330pF/50V,K,TAPING,Y5P) 413-KC220-116
C1017 nsp ELEC. CAPACITOR(100uF/10V,M)(Cd,Pb,Hg,Cr) 413-HMA2200-5017
C1018,1019 nsp ELEC. CAPACITOR(47uF/10V,M,TAPING 4*7,MINI) 413-810-920
C1020 nsp ELEC. CAPACITOR(100uF/10V,M)(Cd,Pb,Hg,Cr) 413-HMA2200-5017
C1021-1026 nsp CHIP CAPACITOR(0.1uF/50V,Z) 413-DCM280-773
OTHER PATRS GROUP
CN1000 nsp 2P SOCKET(CKM2501WV-2P 180°WHITE) 404-KMD1500-608A
CN102A 941644004990P 12P FFC CONNECTOR(52207-1285) 404-4001-2235 *
JK1000 00D9587060904 3P PHONE JACK(6.4,JY-6313-02-030) 420-HMJ1001-5034A
L1000,1001 nsp CORE(100uH) 415-MX3-270
SW1000 941662005010P 2P TACT SW(SFKHLLV1724,H=3.3mm) 403-MC6000-385 *
SW1001 941664005020P SLIDE SW(SSSF122NA1-HF,6PIN) 403-QMX1-060 *
SW1002-1005 941664005030P SLIDE SW(SSSF113NA3-HF,L=6) 403-IM-314 *
VR1000-1004 941671005050P ROTARY V(RD901F-20B3-20F-B20K-0CD16A,L=20mm) 418-MC6000-635 *
VR1005,VR1007 941671005040P ROTARY VR(RD901F-20B3-20F-B20K-00D17A,L20) 418-MC6000-634 *
VR1006 941671005050P ROTARY V(RD901F-20B3-20F-B20K-0CD16A,L=20mm) 418-MC6000-635 *
W600 nsp 4P 2.5 CONNECTOR WIRE(L=630mm) 404-MC6000-3486
JK1000 941445005000P JACK GROUND PLATE JK1000 300-300-1171 *
nsp VR FIXED PLATE 300-6000-1874
nsp EQ PCB(BARE) 405-MC6000-2784
00D9587051706 LED(RED,LTL-16KE,
∮
3) 410-CD6000-122
