45
PARTS LIST OF EXPLODED VIEW
z
Parts for which "nsp" is indicated on this table cannot be supplied.
z
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
z
Parts indicated by the "
★
" mark are not illustrated in the exploded view.
z
The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note:
The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
Ref. No. Part No. Part Name Remarks Q'ty New
1 941443005070P CHASSIS & LED LIDS & CLOTH ASSY 701-6000-4988 1 *
1-1 nsp CHASSIS ASS'Y 701-6000-4887 1 *
1-2 nsp LED LENS 100-1100-2605 20
1-3 nsp LED LENS 100-700-2680 4
1-4 nsp JACKET COVER 100-2000-2775 2
1-5 nsp CUSHION(75*7*0.3t,BLACK) 612-IMR-295 2 *
1-6 nsp CUSHION(64*7*0.3t,BLACK) 612-IM-296 4 *
2 nsp BAR CODE (86*209mm,t=0.1mm) E2 701-MC6000E2-4916 1
2 nsp BAR CODE (86*209mm,t=0.1mm) E3 701-MC6000E3-4916 1
3 nsp WHEEL ASS'Y 701-2000-4922 2
3-1 941412004120P WHEEL & PLATE ASS'Y 701-SC2000-4942 2
3-1-1 nsp WHEEL & SHAFT ASS'Y 701-2000-4815 2
3-1-2 nsp WHEEL PLATE 300-2000-1833 2
3-1-3 nsp SCWER(SAE1018,STS,2.0*3) 602-STS2003-677 2
3-1-4 nsp SPRING(SUS304,
∮
0.3,L=6) 603-M1-384 2
3-2 941483004110P ENCODER PLATE 300-PROS2-848 2
3-3 nsp ENCODER FIXED PLATE 300-PROS2-851 2
3-4 nsp SCREW(PTB,
∮
2*L6) 602-PROS2-363 12
4 nsp BASE ASS'Y 703-6000-1311 1 *
5 nsp SENSOR PCB ASS'Y 704-9800-4687 2
6 nsp CONTROL PCB ASS'Y 704-6000-9561 1 *
7 941639100030P 704-6000-9562 IO PCB ASSY DNMC6000 704-6000-9562 1 *
d
8 nsp MIC EQ PCB ASS'Y 704-6000-9563 1 *
9 nsp CROS FADER PCB ASS'Y 704-6000-9603 1 *
10 00D9410057301 POWER KNOB 100-HDJ2000-1641 1 *
11 90M09CW259020 KNOB PROTECTOR 100-HDJ2000-1642 1 *
12 00D9587012907 ROTATY KNOB(ABS,BLACK) 100-300-2226 5 *
13 00D9587013401 PUSH KNOB 100-300-2231 5 *
14 941412005080P PUSH KNOB(MIDDLE) 100-UDJ3EB-2213 2 *
15 00D9587045709 ROTARY KNOB(ABS) 100-900-2298 8 *
16 941412005090P ROTARY KNOB(ABS) 100-6000-2298 4 *
17 nsp SCREW(
∮
2.6,L=8) 602-BTB2608-708B 8
18 412510031005P ROTARY KNOB 100-1100-2633 1 *
s
19 412510032008P ROTARY KNOB 100-1100-2634 20 *
s
20 941412005100P ROTARY KNOB 100-6000-2634 4 *
21 nsp SEPARATE BOARD(Fe) 300-6000-1890 1 *
22 nsp CABLE CLAMP(PC-1S) 100-K1-2682 1
23 941412003130P JOG TUNING KNOB 100-1000S-2736 1
24 941423004040S JACKET RING 100-2000-2774 1
25 nsp SEPARATE PATE 501-6000-2412 1 *
26 941412005110P ROTARY KNOB(ABS,BLACK) 100-6000-2796 5 *
27 941404005120P SIDE COVER 100-6000-2798 2 *
28 nsp GROUND PIN 200-DJ100-231 1
29 nsp SENSOR FIXED PLATE(SECC,1.2t) 300-HDJ9800-981 2
30 nsp FIXED PLATE FOR SLIDE VR(SECC,1.5t) 300-100-1167 1 *
31 941403005130P TOP PANEL 300-6000-1857 1 *
33 nsp
2P 2.5 CONNECTOR WIRE(L=30mm,AWM1007,AWG26)
404-X120-2832 1
34 nsp
1P LEAD WIRE(L=50mm,AWM1007 AWG26,BLACK)
406-HDJ2100-414 2
35 941606005200P 20P 1.0 RIBBON WIRE & CODE ASS’Y 704-MC6000-9734 1 *
36 90M-YU002200R 12P 1.0 FFC WIER(L=140mm,+/+) 406-4001-836 1 *
39 00D9587051706 LED(RED,LTL-16KE,
∮
3) 410-CD6000-122 1 *
41 nsp DUST-PROOF SLICE 501-HDJ9800-1648 2
42 nsp WIRE MOUNT(FW-2-3M,WHITE) 504-ST100-118 1
43 nsp LED HOUSING(CLED-3CN2B,BLACK,L=5.6) 504-X120-225 1
44 nsp TWIN ADHESIVE 508-2000-110 1
45 nsp NUT(M3*P0.5) 601-A100-004 1
46 nsp PULLEY SPRING 603-PROS2-256A 2
47 941411003870P EFX SOFT KNOB 604-6000-553 2 *
To Next Page
