Denon DN-MC6000 - Troubleshooting Guide; Jog Wheel Scratch Function Troubleshooting

31
FLOW CHARTNo.14 (405-MC6000-2782 : CONTROL UNIT)
O.K.
O.K.
O.K.
N.G.
N.G.
N.G.
JOG WHEEL is not operating.
(Scratch function is not operating.)
When JOG WHEEL is touched, is wavelength of
2pin, 6pin and 12pin changing?
Is waveform inputted to 5pin of IC119?
Check the periphery circuit of JOG WHEEL form
IC120, and replace it if defective.
When the periphery circuit is correct, replace JOG
WHEEL.
Check periphery circuit of IC119 from IC120, and
replace it if defective.
Is waveform inputted to 42pin of IC100?
Check periphery circuit of IC100 from IC119, and
replace it if defective.
When the periphery circuit is correct, replace IC119.
Replace IC100.
O.K.
O.K.
N.G.
N.G.
Is BEND function operating?
Is reference waveform outputted at 2pin,6pin and
12pin of IC120?
Check the periphery circuit of IC120, and replace it
if defective.
When the periphery circuit is correct, replace
IC120.
Refer to FLOW CHART NO.13
<JOG WHEEL is not operating.
(BEND function is not operating.)>.
