7. Booth Outputs (XLR, balanced): Use standard XLR cables to connect these outputs to booth monitors or a
booth amplifier system. Use the Booth knob on the top panel to control the volume level.
8. Master Outputs (XLR, balanced): Use standard XLR cables to connect these outputs to loudspeakers or an
amplifier system. Use the Master knob on the top panel to control the volume level.
9. Master Outputs (RCA, unbalanced): Use standard RCA cables to connect these outputs to loudspeakers or an
amplifier system. Use the Master knob on the top panel to control the volume level.
10. Stereo/Mono: Use this switch to set the channel configuration of the Master Outputs: Stereo (binaural audio
using separate left and right channels) or Mono (summed monaural audio through both left and right channels).
11. Line Inputs (RCA, unbalanced): Use standard RCA cables to connect these line-level inputs to an external
audio source.
12. Line/Phono Inputs (RCA, unbalanced): Use standard RCA cables to connect these line-level or phono-level
inputs to an external audio source.
13. Phono/Line Switch: Flip this switch to the appropriate position, depending on the device connected to the
Line/Phono Inputs. If you are using phono-level turntables, set this switch to Phono to provide the additional
amplification needed for phono-level signals. If using a line-level device, such as a CD player or sampler, set this
switch to Line.
14. Grounding Terminal: If using phono-level turntables with a grounding wire, connect the grounding wire to these
terminals. If you experience a low “hum” or “buzz”, this could mean that your turntables are not grounded.
Note: Some turntables have a grounding wire built into the RCA connection and, therefore, nothing needs to be
connected to the grounding terminal.
15. Mic Inputs (XLR or 1/4” / 6.35 mm): Use standard XLR or 1/4” (6.35 mm) cables (not included) to connect
standard dynamic microphones to these inputs. Use the Mic 1 and Mic 2 Level knobs on the top panel to
control the volume level.
16. Kensington
®
Lock Slot: Use this slot to secure PRIME 4 to a table or other surface.
