Denon RCD-N7 User Manual

13
Getting Started Connections
Advanced ConnectionsBasic OperationsBasic Operations Advanced Operations TroubleshootingExplanation termsInformation Specifi cations Index
ENGLISH
CD playback
This section explains how to playback CDs.
Before playing a disc
1
Press ON/STANDBY.
2
Press <SOURCE> and ui to select to “ ”, then
press [ENTER] , <1/3 ENTER > or p, or press [CD].
If no disc is loaded “No Disc” is displayed.
3
Insert a disc (vpage 3).
• Press <5> to open/close the disc tray.
• The disc tray also closes when <1/3 ENTER> or [1/3] is
pressed.
NOTE
• Do not place any foreign objects in the disc tray. Doing so could
damage it.
• Do not push the disc tray in by hand when the power is turned off.
Doing so could damage the set.
Playing CDs
Press <1/3 ENTER > or [1/3].
The “1” indicator lights and playback begins.
• If the input source is set to something other than “ ”, press [CD]
to switch the input source to “ ”.
• The input source can also be switched to “ ” using <SOURCE>
(vpage12).
n Stopping playback
Press [2].
n Stopping playback temporarily
Press <1/3 ENTER> or [1/3].
3 is displayed.
• To resume playback, press <1/3 ENTER> or [1/3].
n Fast-forwarding and fast-reversing (searching)
During playback, press and hold in [6, 7].
n Moving to the beginning of tracks (skipping)
During playback, press [8, 9] or <o p>.
• The disc skips as many tracks as times the button is pressed.
• When you press reverse once, playback returns to the beginning
of the current track.
n To play the desired track (remote control only)
Press [NUMBER] (0 – 9, +10) to select the track.
GExampleH Track 4 : [4]
GExampleH Track 12 : [+10], [2]
GExampleH Track 20 : [+10], [+10], [0]
Switching the display
Press [DISPLAY].
Elapsed time of
current track
Remaining time
of current track
Remaining time for
all remaining tracks
• The display switches each time the button is pressed.
Setting the sleep timer
Use this function to automatically switch the power to the standby
mode after a specifi c amount of time (minutes).
The sleep timer can be set to up to 90 minutes, in steps of 10 minutes.
Press [SLEEP] during playback and select the setting
time.
• Press the button to select the setting time.
• After about 5 seconds, the setting is entered and the display
returns to as it was before.
n Canceling the sleep timer
Either press [SLEEP] to select “Sleep1OFF” or press ON/
STANDBY
.
n To check the time remaining until the sleep
timer is activated
Press [SLEEP].
Switching the display’s brightness
Press [DIMMER].
100% 75%
50%25%Off
• The display’s brightness switches each time the button is pressed.
If you operate the buttons when the display’s brightness is set to
“Off”, the display temporarily lights at 25% brightness level.
Listening with headphones
Plug the headphones (sold separately) into < >.
• The sound from the speakers is automatically cut off.
NOTE
To prevent hearing loss, do not raise the volume level excessively
when using headphones.
Operations possible during playback
1.RCDN7E2ENG5th0831.indd131.RCDN7E2ENG5th0831.indd13 2010/09/0115:09:562010/09/0115:09:56

Denon RCD-N7 Specifications

General

Frequency range	5 - 20000 Hz
RMS rated power	65 W
Pre-out channels	1 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Dynamic power per channel (4 Ohm)	80 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio (L/R) in	2
Digital audio optical in	1
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WMA
Image formats supported	JPG
Video formats supported	AVI, WMV
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	99
Internet radio services supported	Last.fm, Napster
Optical drive type	CD player
Disc types supported	CD, CD-R, CD-RW
Display	OLED
Product color	Silver
Audio decoders	Not supported
Volume control	Rotary
Apple docking compatibility	iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.4 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4300 g
