Denon RCD-N7 User Manual

29
Getting Started Connections
Basic Operations Advanced OperationsAdvanced Operations TroubleshootingExplanation termsInformation Specifi cations Index
ENGLISH
Connecting Wireless LAN
If you cancelled “Network First Setup” or changed the network
environment, perform “Menu” − “Network” − “Network First Setup”.
n Search Access Point (Wireless LAN)
1
Fitting a rod antenna.
If a LAN cable is connected, remove it.
2
Turn on this unit.
(vpage11 “Turning the power on”)
3
Press [MENU].
Turns on the menu settings mode and the menu appears on
the display. (vpage25 “Menu map”)
4
Use ui to select “Network” – “Connection” –
“Search Access Point”, then press [ENTER], <1/3
ENTER > or p.
The access point you have set is displayed.
5
Use ui to select the access point, and then press
[ENTER], <1/3 ENTER > or p.
If the access point is not detected automatically, use the
“Manual Settings” (vpage30) procedure.
6
If there is an encryption setting for the access point
you selected in step 5, enter same encryption key as
used for the access point. (If there is no encryption
setting, proceed to step 7.)
Use uio p to input the “Key” (encryption key) and press
[ENTER], <1/3 ENTER> or p. Enter the same encryption key
as used for the access point.
• The types of characters that can be input are as shown below.
G Upper case charactersH
ABCDEFGHIJKLMNOPQRSTUVWXYZ
GLower case charactersH
abcdefghijklmnopqrstuvwxyz
GSymbolsH
! “ # $ % & ‘ ( )
z
+ , - . / : ; < = > ? @ [ \ ] ^ _ ` { | }
˜
GNumbersH
0123456789 (Space)
• When no security settings have been used in the Internet connection
settings, this step is not necessary.
7
Use i to select “Connection”, then press [ENTER],
<1/3 ENTER > or p.
Network connection starts.
• This unit performs automatic network setup due to the DHCP
function.
• When connecting to a network that has no DHCP function, perform
the setting in Network conntecting (DHCP=Off) (vpage28).
n WPS Settings (Push-button method)
1
Press [MENU].
Turns on the Menu settings mode and the Menu appears on
the display. (vpage25 “Menu map”)
2
Use ui to select “Network” – “Connection” –
“WPS” – “Push Button”, then press [ENTER], <1/3
ENTER > or p.
3
Use ui to select “Enter”, then press [ENTER],
<1/3 ENTER > or p.
Please push the WPS button of the router, and push the Enter
button of the machine.
4
When connection is established with access point,
“Succeeded” is displayed.
n WPS Settings (PIN code method)
1
Press [MENU].
Turns on the Menu settings mode and the Menu appears on
the display. (vpage25 “Menu map”)
2
Use ui to select “Network” – “Connection” –
“WPS” – “PIN code”, then press [ENTER], <1/3
ENTER > or p.
The access point you have set is displayed.
3
Use ui to select the access point, then press
[ENTER], <1/3 ENTER >, or p.
PIN code number is displayed.
4
Set this PIN code to the register.
When connection is established with access point,
“Succeeded” is displayed.
n Proxy Settings
Make this setting when connecting to the Internet wia to proxy
server.
1
Press [MENU].
Turns on the Menu settings mode and the Menu appears on
the display. (vpage25 “Menu map”)
2
Use ui to select “Network” – “Connection” –
“Proxy”, then press [ENTER], <1/3 ENTER > or p.
“Proxy” setting menu appears.
3
If “Proxy(On)” appears, go to step 5.
If “Proxy(Off)” appears, press [ENTER], <1/3
ENTER >, or p.
“Proxy” (On/Off) setting menu appears.
4
Use ui to select “On”, then press [ENTER], <1/3
ENTER > or p.
“Proxy” setting menu appears.
5
Use ui to select “Proxy (Address)” or “Proxy
(Name)”, then press [ENTER], <1/3 ENTER > or p.
“Select Type” setting menu appears.
• Seleccione si Proxy es una dirección de servidor o un nombre de
dominio.
6
Use ui to select “Address” or “Name”, then
press [ENTER], <1/3 ENTER > or p.
“Proxy” setting menu appears.
7
Use ui to select “Address” or “Name”, then press
[ENTER], <1/3 ENTER > or p.
“Address” or “Name” input menu appears.
• Input a server address or domain name.
8
Use uip or [NUMBER] (0 – 9) to input the address
or name, then press [ENTER] or <1/3 ENTER >.
“Proxy” setting menu appears.
9
Use ui to select “Port”, then press [ENTER], <1/3
ENTER > or p.
“Port” input menu appears.
10
Use ui p or [NUMBER] (0 – 9) to input the port,
then press [ENTER] or <1/3 ENTER >.
The Proxy settings are completed.
Setting the network [Network]
1.RCDN7E2ENG5th0831.indd291.RCDN7E2ENG5th0831.indd29 2010/09/0115:10:032010/09/0115:10:03

Denon RCD-N7 Specifications

General

Frequency range	5 - 20000 Hz
RMS rated power	65 W
Pre-out channels	1 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Dynamic power per channel (4 Ohm)	80 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio (L/R) in	2
Digital audio optical in	1
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WMA
Image formats supported	JPG
Video formats supported	AVI, WMV
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	99
Internet radio services supported	Last.fm, Napster
Optical drive type	CD player
Disc types supported	CD, CD-R, CD-RW
Display	OLED
Product color	Silver
Audio decoders	Not supported
Volume control	Rotary
Apple docking compatibility	iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.4 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4300 g
