18
ENGLISH
NOTE
• iPod nano 1G and iPod video do not have remote mode support.
• DENON will accept no responsibility whatsoever for any loss of iPod
data.
• Depending on the type of iPod and the software version, some
functions may not operate.
n Remote control and iPod button relations
Remote control
buttons
iPod buttons Operation on this unit
1/313
Play the track / Pause the track.
8, 98, 9
Play the track from the beginning/Play the
next track.
6, 7
Press and hold
8, 9
Press and hold
Fast-reverse the track/Fast-forward the
track.
u, i
Click Wheel Select an item.
ENTER or p
Select Enter the selection or plays the track.
MODE
–
Switch between the browse mode and
the remote mode.
REPEAT
– Switch the repeat function
RANDOM
– Switch the shuffl e function
o
MENU
Display the menu or return to the previous
menu.
2
– Stop the track.
HOME
– Return to top menu (in Browse mode)
n To switch the display
During playback, press [DISPLAY].
The display switches each time the button is pressed.
Artist name
Album name
Disconnecting the iPod
1
Press ON/STANDBY to set the standby mode.
2
Remove the iPod from the iPod dock of this unit.
Button located on both the main unit and the remote control
BUTTON
Button only on the main unit <BUTTON>
Button only on the remote control [BUTTON]
Symbols used to indicate buttons in this manual
u
p
[ENTER]
i
[SEARCH]
[6]
[7]
[MODE]
[8]
[9]
[2]
ON/STANDBY
[INTERNET RADIO]
[USB]
[1/3]
[RANDOM]
[REPEAT]
o
[DISPLAY]
[HOME]
/&5803,$%3&$&*7&33$%/
p i
<1/3 ENTER><SOURCE>
o
u
ON/STANDBY
USB memory device playback
Playing back music or fi les recorded on a USB memory device or an
iPod.
n USB memory device (vpage42)
n Playing an iPod (vpage17)
Before playing a USB memory device or an
iPod
1
Press ON/STANDBY.
2
Connect USB memory device or iPod connection
cable.
3
Press <SOURCE> and ui to select to “ ” , then
press [ENTER] , <1/3 ENTER > or p, or press [USB].
NOTE
This function is activated around 1 or 2 minutes after the power is
turned on.
Playing fi les stored on USB memory
devices
1
Press ui to select the search item or folder, then
press [ENTER], <1/3 ENTER > or p.
2
Press ui to select the fi le, then press [ENTER],
<1/3 ENTER >, p or [1/3].
Playback starts.
• If the USB memory device is divided into multiple partitions, only the
top partition can be selected.
• This unit is compatible with MP3 fi les conforming to “MPEG-1 Audio
Layer-3” standards.
iPod
®
playback
1.RCDN7E2ENG5th0831.indd181.RCDN7E2ENG5th0831.indd18 2010/09/0115:09:582010/09/0115:09:58

Denon RCD-N7 Specifications

General

Frequency range	5 - 20000 Hz
RMS rated power	65 W
Pre-out channels	1 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Dynamic power per channel (4 Ohm)	80 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio (L/R) in	2
Digital audio optical in	1
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WMA
Image formats supported	JPG
Video formats supported	AVI, WMV
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	99
Internet radio services supported	Last.fm, Napster
Optical drive type	CD player
Disc types supported	CD, CD-R, CD-RW
Display	OLED
Product color	Silver
Audio decoders	Not supported
Volume control	Rotary
Apple docking compatibility	iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.4 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4300 g
