Denon RCD-N7 User Manual

16
ENGLISH
Automatically presetting FM stations
(Auto preset)
This unit can be preset with a total of 99, FM and AM broadcast
stations.
NOTE
Auto preset is not possible with AM broadcast stations.
n Auto presetting with the remote control
Perform this operation when tuned to an FM broadcast station.
1
Press [SEARCH].
“Search” menu appears.
2
Use ui to select “Auto Preset” – “Start”, then
press [ENTER], <1/3 ENTER > or p.
After “Searching“ is displayed, “Complete“ is displayed.
Canceling auto presetting
Press [2].
Broadcast stations whose antenna signal are weak cannot be preset
automatically. If you wish to preset such stations, tune them in
manually.
NOTE
When the auto presetting operation is performed, the new presettings
overwrite the previous presettings.
n Giving station names to preset channels
Names of up to 8 characters can be input.
1
Tune in the preset channel you want to name.
2
Press and hold [ENTER] or <1/3 ENTER >.
The display switches to the station name input display.
3
Input the station name.
“Inputting characters” (vpage34)
4
Press [ENTER] or <1/3 ENTER >.
The characters you have input are entered.
• To give names to other stations, repeat steps 1 to 4.
Tuner playback
Tuning in Broadcast Stations
Connect the antenna beforehand (vpage7).
1
Press [TUNER] to select the reception band.
AM FM
2
Tune in the desired broadcast station. (FM/AM only)
When a station is received, the “ ” will light.
q To tune in automatically (Auto tuning)
Press [MODE] to light the “AUTO” indicator on the display, then
use [TU d, TU f] to select the station you want to hear.
w To tune in manually (Manual tuning)
Press [MODE] to turn off the display’s “AUTO” indicator, then use
[TU d, TU f] to select the station you want to hear.
• If the input source is set to something other than “TUNER”, press
[TUNER] to switch the input source to “TUNER”.
• The input source can also be switched to “FM” or “AM” using
<SOURCE> (vpage12).
• If the desired station cannot be tuned in with auto tuning, tune it in
manually.
• When tuning in stations manually, press and hold [TU d, TU f] to
change frequencies continuously.
• A humming sound may be heard when using a TV nearby while
receiving AM programs. If this happens, move the system as far
from the TV as possible.
n To stop auto tuning
Press [TU d, TU f].
Button located on both the main unit and the remote control
BUTTON
Button only on the main unit <BUTTON>
Button only on the remote control [BUTTON]
Symbols used to indicate buttons in this manual
o
i
u
p
[SEARCH]
[TUNER]
[CHANNEL + - ]
[2]
[NUMBER]
[MODE]
[ENTER]
[TUf]
[TUd]
ON/STANDBY
/&5803,$%3&$&*7&33$%/
p i
<1/3 ENTER><SOURCE>
o
u
ON/STANDBY
1.RCDN7E2ENG5th0831.indd161.RCDN7E2ENG5th0831.indd16 2010/09/0115:09:582010/09/0115:09:58

Denon RCD-N7 Specifications

General

Frequency range	5 - 20000 Hz
RMS rated power	65 W
Pre-out channels	1 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Dynamic power per channel (4 Ohm)	80 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio (L/R) in	2
Digital audio optical in	1
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WMA
Image formats supported	JPG
Video formats supported	AVI, WMV
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	99
Internet radio services supported	Last.fm, Napster
Optical drive type	CD player
Disc types supported	CD, CD-R, CD-RW
Display	OLED
Product color	Silver
Audio decoders	Not supported
Volume control	Rotary
Apple docking compatibility	iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.4 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4300 g
