Denon RCD-N7 User Manual

45
Getting Started Connections
Basic Operations Advanced Operations TroubleshootingTroubleshootingInformation Specifi cations Index
ENGLISH
Explanation terms
If a problem occurs fi rst check the following:
1. Are the connections correct?
2. Is the set being operated as described in the owner’s manual?
3. Are the other components operating properly?
If this unit does not operate properly, check the items listed in the table below. If the problem persists,
there may be a malfunction.
In this case, disconnect the power immediately and contact your retail outlet.
GGeneralH
Symptom Cause Countermeasure Page
Set does not
operate properly.
• External noise or interference is
causing the set to malfunction.
• Reset the microprocessor. 35
Display not lit
and sound not
produced when
power switched
to on.
• Power cord not plugged in
securely.
• Check the connections on
the set's rear panel and the
connection of the power plug to
the power outlet.
10
Display lit but
sound not
produced.
• Wrong input source selected.
• Volume control set to minimum.
• MUTING is on.
• Select the appropriate input
source.
• Turn volume up to suitable level.
• Switch off MUTING.
12
12
12
Display is off. • The Dimmer setting is set to
“OFF”.
• Set to something other than
“OFF”.
13
Power turns off
suddenly and
POWER indicator
fl ashes red.
(Flashes at 0.5
second intervals)
• Core wires of two speakers
are touching each other or a
core wire is sticking out of
the terminal and touching the
set’s rear panel, activating the
protection circuit.
• First unplug the power cord,
then twist the core wires tightly
or terminate the speaker cables,
then reconnect.
5
Power turns off
suddenly and
POWER indicator
fl ashes red.
(Flashes at 0.25
second intervals)
• Set is damaged. • Turn off the power and contact
a DENON service center.
–
Power turns off
suddenly and
POWER indicator
fl ashes red.
(Flashes at 2
second intervals)
• Protection circuit activated due
to a rise in internal temperature.
• Turn off the power, wait for the
set to fully cool down, then turn
the power back on.
• Place the set in a well-ventilated
location.
6
IV
Troubleshooting
WPA (Wi-Fi Protected Access)
This is a security standard established by the Wi-Fi
Alliance. In addition to the conventional SSID
(network name) and WEP key (network key), it also
uses a user identifi cation function and encrypting
protocol for stronger security.
WPA2 (Wi-Fi Protected Access 2)
This is a new version of the WPA established by the
Wi-Fi Alliance, compatible with more secure AES
encryption.
WPA-PSK/WPA2-PSK (Pre-shared Key)
This is a simple authentication system for mutual
authentication when a preset character string
matches on the wireless LAN access point and
client.
WPS (Wi-Fi Protected Setup)
This is a standard drawn up by the Wi-Fi Alliance
to ease the task of setting up wireless LAN
connections and confi guring security.
There are two methods: push-button and PIN (Personal
Identifi cation Number) code.
1.RCDN7E2ENG5th0831.indd451.RCDN7E2ENG5th0831.indd45 2010/09/0115:10:062010/09/0115:10:06

Denon RCD-N7 Specifications

General

Frequency range	5 - 20000 Hz
RMS rated power	65 W
Pre-out channels	1 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Dynamic power per channel (4 Ohm)	80 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio (L/R) in	2
Digital audio optical in	1
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WMA
Image formats supported	JPG
Video formats supported	AVI, WMV
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	99
Internet radio services supported	Last.fm, Napster
Optical drive type	CD player
Disc types supported	CD, CD-R, CD-RW
Display	OLED
Product color	Silver
Audio decoders	Not supported
Volume control	Rotary
Apple docking compatibility	iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.4 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4300 g
