42
(2) Prefix/Suffix
A prefix or suffix consists of up to five ASCII characters (00h to FFh).
The default is no prefix. You can specify a prefix or suffix with the configuration software (ScannerSetting).
(3) Code ID mark
This optional field specifies the bar code symbology. Five types of code ID marks are available as listed below. (Default:
Type 1)
You can also select whether or not to transmit the code ID mark. (Default: No transmission)
Code ID mark
Bar code systems
Type 1
(DENSO 1)
Type 2
(DENSO 2)
Type 3 Type 4
Type 5
(AIM)*
UPC-A A C A ]X0
UPC-E C E D A ]X0
EAN-13 A F B A ]E0
EAN-8 B FF A A ]E4
UPC-A with 2-digit add-on A F A ]X1
UPC-A with 5-digit add-on A G A ]X2
UPC-E with 2-digit add-on C E H A ]X1
UPC-E with 5-digit add-on C E I A ]X2
EAN-13 with 2-digit add-on A F L A ]E1
EAN-13 with 5-digit add-on A F M A ]E2
EAN-8 with 2-digit add-on B FF J A ]E5
EAN-8 with 5-digit add-on B FF K A ]E6
Standard 2of5 (short) H O G ]R0
Standard 2of5 (normal) H O G ]S0
Interleaved 2of5 I N F ]Im
Code 39 M V B ]Am
Code 39 Full ASCII M W B ]Am
Codabar (NW-7) N R C ]Fm
Code 93 L U E ]G0
Code 128 K T D ]Cm
EAN-128 W k K ]C1
MSI P Z J ]M1
Plessey T a T ]P0
* Type 5 is a code ID mark system compliant with the AIM USA "Guidelines on Symbology Identifiers." The "m" suffix differs
depending upon the data transmission format of each bar code symbology.
