Denso GT10B-SU - Appendix 1 Specifications

76
Appendix 1 Specifications
Item
GT10B-SU/GT11B-SU
GT10B-LU
Readable bar codes EAN-13, EAN-8, UPC-A, UPC-E, UPC/EAN with add-on,
Interleaved 2of5, Standard 2of5, Code 39, Codabar
(NW-7), Code 93, Code 128, EAN-128, MSI, and Plessey
Scanning direction Bidirectional
Scanning resolution GT10B-SU/GT11B-SU: 4.9 mils (0.125 mm)
GT10B-LU: 7.5 mils (0.19 mm)
Elevation angle (skew) ±40° (∗
1
)
Tilt angle (pitch) ±20° (∗
1
)
Light source LED set (red)
Scanning specifications
Reading confirmation Indicator LED, beeper, and vibrator
Interface - USB keyboard interface
- USB-COM interface
Operating voltage range 5.0 VDC ±5% Input power requirements
Power consumption in
Auto-off mode 1
(Typical at 5.0 VDC)
In operation: 170 mA
On standby: 25 mA
In suspend mode: 0.5 mA
Operating temperature range 0 to 50°C
Operating humidity range 10 to 90% RH (Without condensation or freezing, wet-bulb
temperature 30°C max.)
Storage temperature range -10 to 60°C (∗
2
)
Storage humidity range 5 to 95 %RH (∗
2
)
Environmental conditions
Ambient illuminance range Max. 10,000 lux
Dimensions (W) x (D) x (H) 3.2 x 4.1 x 6.5 inches (82 x 103 x 165 mm)
Weight Approx. 200 g (excluding the cable)
Body color GT10B-SU/GT10B-LU: Black
GT11B-SU: White
(
∗
1)
Under these conditions
- EAN-13 and EAN-8 labels conforming to EAN SYMBOL SPECIFICATIONS
- Magnification ratio: 1.0
- Space reflectance: 0.8
- Bar reflectance: 0.1
- Black bars on a white background
(
∗
2)
Sharp temperature change, dewing or freezing not allowed, wet-bulb temperature 30°C max.
