15
(2) Using the coupling (STT), rotate the drive shaft
until it is directly opposite (180 degrees) from
the element to remove.
• STT: Coupling (95095-20110)
(3) Loosen the four hexagonal bolts on top of the
element sub-assembly.
• STT: Hexagonal Bit (95093-10040)
• STT: Driver Chuck (95992-10130)
NOTE:
Loosen them uniformly in order as shown at
right.
(4) Pull the element sub-assembly until it faces
straight up and remove the element sub-as-
sembly, plunger, and spring.
Key
Q000043E
QD0882
QD1853
[1]
[2]
[4]
[3]
QD0884
To Next Page
