Denso HP3 - Page 20

17
NOTE:
Please secure it so that the vise will not touch
the circled part at right.
(8) Loosen the three hexagonal bolts on top of the
element sub-assembly.
NOTE:
Loosen them uniformly in order as shown at
right.
(9) Pull the element sub-assembly until it faces
straight up and remove the element sub-as-
sembly, plunger, and spring.
QD0889
QD0890
QD1854
[3]
[2]
[1]
QD0892
