74
Modbus Offset Register
Detailed Description
* System=sum of three phases
47051 7050 Negative Displacement PF L2 “
47052 7051 Negative Displacement PF L3 “
47053 7052 Negative Apparent PF L1 Individual Phase Negative Apparent Power Factors
(aPF); Register is 100x actual value (If the Individual
aPF (44053) is Negative, this register will contain that
value else it will be zero)
47054 7053 Negative Apparent PF L2 “
47055 7054 Negative Apparent PF L3 “
47056 7055 Amps L1 Individual Phase Instantaneous Currents (A)
47057 7056 Amps L2 “
47058 7057 Amps L3 “
47059 7058 Volts L1 to Neutral Individual Instantaneous Phase to Neutral Voltages
(V)
47060 7059 Volts L2 to Neutral “
47061 7060 Volts L3 to Neutral “
47062 7061 Time Since Reset LSW (Seconds) Seconds since kWh, kVAh, kVARh and associated
Demand registers were reset. LSW (resettable)
47063 7062 Time Since Reset MSW
(Seconds)
Seconds since CAM. MSW
47080 7079 Negative kW System Average Equals Negative KWH_SYSTEM_L&M ÷
(TimeSinceReset_L&M seconds /3600 seconds/Hr)
(resettable)
47081 7080 kW Demand System Minimum Min Average power window (kW)
47082 7081 kVA Demand System Maximum Maximum Instantaneous kVA Demand (kW,
resettable).
47083 7082 kVA Demand System Now System Average kVA Demand for the most recent
(current) Demand Window (resettable).
