8.2.4. High Alarm Limit Option
The High Alarm Limit option sounds an alarm and turns on a light when a high limit
condition occurs.
Silence the alarm horn by pressing the alarm silence switch. The light remains ON.
Clear the high limit condition to clear the alarm. See Troubleshooting (Section 7) for
solutions to high limit conditions.
Reset the Hi-Limit instrument whenever it has tripped. Reset the Hi-Limit Instrument
by allowing the oven chamber to cool slightly (or by setting the Hi-Limit Instrument
by several degrees) and pushing .
Each oven schematic (Section 0) shows the wiring for this option.
8.2.5. Recorder Option
The circular chart recorder uses and independent thermocouple to record the user’s
process. Charts used are either 24 hour or 7 day. See the recorder manufacturer’s manual
supplied with this manual.
Each oven schematic (Section 0) shows the wiring for this option.
8.2.6. Stacking Kit Assembly Instructions (Only for models LBB1-
23, LBB1-43 and LBB1-69 )
1. Locate the four stacking kit brackets found in the kit.
2. Place each of the brackets on top of each of the four corners of one of the lower ovens
in the stack being assembled.
3. Slide the angle of each bracket into the slots in the embossed area on top of the oven
(Figure 26).
4. Use the four 10-16 x .50 screws included in the kit to attach the brackets to the oven
top.
5. Place the upper oven onto the lower one. The embossed feet on the upper oven should
fit into the brackets attached in the last three steps.
