flowmeter for adjusting purge rate, and needle valve for setting maintain rate,
separate solenoid valves for purge and maintain operation and a pressure relief
exhaust port. An exhaust fan which powers ON whenever the oven is running
maintains consistent chamber pressure control with varied exhaust stack
conditions.
Danger!
Use care when working with nitrogen. Nitrogen presents an
asphyxiation hazard. Handle nitrogen according the safe
handling procedures listed in the material safety data sheet.
The oven has a type 304-2B stainless steel interior and a type 304-#4 stainless
steel exterior. All interior seams are continuously welded on the insulation side.
This protects the work chamber from contaminated air and permits chamber
washing without damaging the insulation. Interior ductwork may be easily
removed for cleaning. Heater frame, fan wheel and motor shaft are constructed
of stainless steel.
Two electropolished stainless steel wire shelves are provided. The shelves are
removable and adjustable on two-inch centers.
The LCC/LCD series design offers a stackable oven body. Multiple oven systems of
two or three oven stack options are available. When operating multiple ovens,
network the Despatch Protocol 3 controllers together with a Modbus
communication option. Use the optional Despatch Protocol Manager software to
enable customer PC control of multiple ovens.
Stackable units are available in air or nitrogen atmosphere
models. Nitrogen atmosphere models are noted with an N suffix.
Model numbers beginning with “LL*1-*” do not use a HEPA filter.
