3. Open door and release DOOR RELEASE (Figure 26).
6.5.2. To Close the LCC/LCD1-51 Oven Door
1. The door latch should be
perpendicular to the oven door while
in the open position (Figure 26).
2. Close the door and press the door
latch all the way closed (Figure 27).
Do not forcefully slam the door
closed.
Figure 26. Oven door latch and door fully
open (latch perpendicular to oven door).
Figure 27. Door fully close and latch fully
engaged.
