6.4.3. Sequence of Operation for LCC/LCD Ovens Equipped
with Optional Beacon Light
1. After starting the oven (refer to Section 6.4.2), the Protocol 3 controller
initializes.
a. The oven should be idle, empty, with the door closed and awaiting the
next lot for processing.
b. The Protocol 3 Controller should not be running a profile.
2. Open the oven door.
The amber beacon light (Figure 8) will be ON (steady) until the
profile is started (at the completion of Step 5)
3. Place the product on the shelf in the oven.
4. Close the oven door.
5. Run the desired profile with the Protocol 3 Controller.
Press Run at any time to activate the Profile Mode.
a. Press Select until Profile is displayed.
b. Press ▲ or ▼ to display the desired profile.
c. Press Run to start the Profile Mode.
After pressing Run, the display changes from Stop to Run.
Segment time remaining and Current Segment number will
display.
6. At this point, the oven profile cycle is in process and the door is locked.
a. The green beacon light is ON (steady), the amber beacon light is off.
b. When the process is complete, the amber beacon should be ON, and the
DOOR RELEASE pushbutton light is on.
7. Press DOOR RELEASE pushbutton.
8. Open the oven door to remove the product workload.
9. Close the oven door to complete the process cycle. The oven is ready for the
next lot.
