Detecto APEX Series User Manual

3300-0188-0M Rev L y apex Digital Scale Owner’s 24
'*2 (USB Mode)
The display will show '*2 and the current setting. If the value displayed is acceptable,
press the key. Otherwise, press the
× or Ø keys to toggle the USB Mode between
$3 (Personal Healthcare Device Class), !!(0 (Welch Allyn) or *00 (SMA, Weight-
On-Demand) and then press the
key to save it and proceed to the next prompt.
This setting controls the output for the USB device port. Allowable settings are $3,
!!(0, or *00.
If $3 (Personal Healthcare Device Class) was selected for USB, the scale will transmit
data using the CEN ISO/IEEE 11073 Medical / Health Device Communication Standard.
If !!(0 (Welch Allyn) was selected for USB, the scale will automatically transmit data to a
Welch Allyn CVSM Device when the weight on the scale stabilizes and the [\ (STABLE)
annunciator turns on. (Requires device to have an activated license. Must purchase Detecto
WACONNECT)
If *00 (SMA, Weight-On-Demand) was selected for USB, and the scale is connected to a
computer for transmission of weight data to a PC-based EMR (electronic medical record)
software program, it will transmit a single set of weight data each time the computer sends a
weight request “ENQ” (hex 05) or a SMA weight request “W”.
=9 (YEAR)
The display will show (9 and the current setting. If the value displayed is acceptable,
press the
key. Otherwise, press the × or Ø keys to select a new value and then press
the
key to save it and proceed to the next prompt.
This is the current year setting of the real time clock. Allowable values are 2015 to 2099.
00;, (MONTH)
The display will show 00; and the current setting. If the value displayed is acceptable,
press the key. Otherwise, press the
× or Ø keys to select a new value and then press
the
key to save it and proceed to the next prompt.
This is the current month setting of the real time clock. Allowable values are 1 to 12.
1 = January 5 = May 9 = September
2 = February 6 = June 10 = October
3 = March 7 = July 11 = November
4 = April 8 = August 12 = December
3( (DAY)
The display will show 3( and the current setting. If the value displayed is acceptable,
press the
key. Otherwise, press the × or Ø keys to select a new value and then press
the
key to save it and proceed to the next prompt.
This is the current day setting of the real time clock. Allowable values are 1 to 31.
