3300-0188-0M Rev L y apex Digital Scale Owner’s 38
PARTS IDENTIFICATION
BASE SUB-ASSEMBLY
Item Qty. Part Number Description
1 1 3300-0053-08 COLUMN CLAMP
2 1 3300-0058-28 SOCKET COVER, APEX
3 2 3300-0059-08 WHEELS
4 2 3300-0082-08 LOAD CELL SPACER
5 1 3300-0086-0A APEX WEIGHBRIDGE
6 1 3300-0094-0A APEX BASE WELDMENT
7 1 3300-0136-1A CABLE, APEX BATTERY
8 1 3300-0138-1A CABLE, APEX LOAD CELL
9 1 3300-0147-0A SUB-ASSY, PLATFORM COVER, APEX
10 4 6013-0049 NUT 1/4-20 HEX JAM
11 2 6013-2006 PUSH NUT, 1/4”
12 4 6013-2008 NUT 1/4-20 CAGE Z/P
13 4 6021-0654 SCW PAN-HEAD, MACHINE-SCW 06-32X.250
14 4 6021-1417 SCW SOCKET-HD. CAP-SCREW,,.25-20X2.0
15 8 6021-1550
SCW FLAT-HEA, CAP-SCREW M8X1.25X30MM
16 4 6540-1122
FOOT, RUBBER, N .81 DIAMETER, ADHESIVE
17 A/R 6560-1061 ADHESIVE LOCTITE 262-21 THREADBLOCKER, HS
18 1 6690-0001 LEVEL, "BULLSEYE" TYPE
19 1 593GR986 SERIAL TAG ASSY
