Model
Number of cylinders
Cylinder arrangement
Bore [mm]
Stroke [mm]
Total displacement [cm
3
]
Compression ratio [e]
Working cycle
Combustion system
Direction of rotation
Weight without cooling system
(without starter, with generator) ca. [kg]
Engine power [kW (PS)]
Speed [1/min]
Lubrication
SAE oil
Maximum oil temperature in the oil sump [°C]
Minimum oil pressure in warm condition, oil temperature 110 °C,
at: 900/min (low idling speed) [bar]
1800 /min [bar]
max. 3000 /min [bar]
Engine with Thermostat
Oil change quantity without external cooler (see 3.1.1.2)/ without filter approx.
[ltr.]
Oil change quantity without external cooler (see 3.1.1.2) + filter replacement
[ltr.]
(Standard 0.5 litre) approx.
Genset engine without Thermostat:
Oil change quantity including cooler (see 3.1.1.3)/ without filter approx.
[ltr.]
Oil change quantity including cooler (see 3.1.1.3) + filter replacement [ltr.]
(Standard 0.5 litre) approx.
Valve clearance at cold engine
(Engine cooling time at least 30 mins.: oil temperature below 80°C) [mm]
Start delivery [°crank angle b TDC]
Injector opening pressure: vehicle/genset engine [bar]
Firing order of the engine
V-Belt tension: Pretension / Retension(after the engine has been running under load for 15 mins):[N]
——— F3M 1011F ———————— F4M 1011F ——
————— 3 ———————————— 4 ————
—————————— vertical in line ————————
———————————— 91 ———————————
————— 112 ———————————— 112 ———
———— 2184 ——————————— 2912 ———
———————————— 18,5 —————
———————— 4-stroke diesel engine ———————
————— naturally aspirated engine with direct injection
————————— counter clockwise ————————
———————— Rückfrage Stammhaus ———————
————— 200 ———————————— 242 ———
———————————— 1) ———————————
————————————
1)
———————————
———————— Druckumlaufschmierung ——————
——————————— 20 W 20 ——————————
———————————— 130 ——————————
——————————— 1,4 3) ——————————
——————————— 2,2
3)
——————————
———————————— 3
3)
——————————
———— 5,5
2)
——————————— 10
2)
———
————— 6
2)
——————————— 10,5
2)
———
———— 8,5
2)
——————————— 13
2)
———
————— 9
2)
——————————— 13,5
2)
———
—————————————
—————————————
—————— inlet 0,3
+
0,1
/ exhaust 0,5
+
0,1
————
————————————
1)
———————————
—————————— 210 / 250
+8
—————————
———— 1 - 2 - 3 ————————— 1 - 3 - 4 - 2 ——
—————— 450 / 350 ±20 ————————
/ ———
Technical Specifications
1)
Engine power, speed, start of delivery are stamped on engine rating plate, see also 2.1.
2)
Ca. value can vary depending on oil sump and or coolor design (external cooling system).T
he upper oil dipstick marking should always be taken as authoritative.
3)
Values for engines without engine oil heating.
