3.3 DISPERSION TUBE POSITIONING
Steam dispersion tubes:
the steam from the humidifier is injected in a duct or an air handling unit via a steam dispersion tube. To obtain the
best performance of the humidifier, select the longest pipe.
Fig. A 3-3. Steam dispersion tubes positioning
Spirit level
Threaded rod
