ELECTROVAP® ELMC
48
6.2 STEAM CYLINDER CLEANING
ESTIMATED CYLINDER MAINTENANCE CURVE
X – steam demand
Example: for a humidifier operating at 100% capacity, using water with a TH20, the cylinder will need to be cleaned or
changed after 800-900 hours of operation.
• The water hardness is expressed in French degrees. The value thus expressed refers to the hygrometric titre
of the water (TH).
• The water quality must be specified when choosing your unit in order to adapt the cylinder to your
type/quality of water.
ELECTRODE CHANGE
Original length
Type
ELMC 5 to 15
ELMC 20 to 90 and ELMC 10 MONO
Length [mm]
160
250
The electrodes must be changed when their length is less than 1/3 of the original length.
ElectroVap ELMC are equipped as standard with cleanable cylinders that can be disassembled using two 8 keys.
