ELECTROVAP® ELMC
23
3.8 ELECTRICAL WIRING
Up [V] = POWER VOLTAGE
Uc [V] = CONTROL VOLTAGE
ELMC
3
4
1
2
L
1
L
2
L
3
N
L
Up(V) = 1x200 - 230Vac (50-60Hz)
Electrical isolator +
Protection
Up(V)
Up(V) = 3x200 - 230Vac (50-60Hz)
ELMC
3
4
1
2
L
1
L
2
L
3
N
L
Electrical isolator +
Protection
Up(V)
ELMC
3
4
1
2
L
1
L
2
L
3
N
L
Up(V) = 3x380 - 690Vac (50-60Hz)
Uc (V) = 1x200 - 230Vac (50-60Hz)
Uc(V)
Up(V)
Electrical isolator
+
Protection
Up(V) = 3x380 - 420Vac (50-60Hz)
with neutral
ELMC
3
4
1
2
L
1
L
2
L
3
N
L
Up(V) + Neutral
Electrical isolator
+
Protection
